NSN 5990-00-814-7989 NAS62323, NAS623-2-3 , 4556221
Product Details | CONTROL TRANSFORMER SYNCHRO
5990-00-814-7989 A synchro consisting of a stator and rotor inductively coupled. The electrical output of the rotor is dependent upon both the position of the rotor and the electrical input to the stator from a transmitter synchro or a differential synchro. Does not include variable resistors, goniometers, or variable transformers.
Part Alternates: NAS62323, NAS623-2-3 , 4556221, 455622-1, 5990-00-814-7989, 00-814-7989, 5990008147989, 008147989
Electrical and Electronic Equipment Components | Synchros and Resolvers
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1962 | 00-814-7989 | 15289 ( SYNCHRO, CONTROL TRANSFORMER ) |
Drawings & Photos | NSN 5990-00-814-7989
Demand History | NSN 5990-00-814-7989
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| NAS62323 | 2022-01-19 | 120 | Malaysia |
| NAS62323 | 2021-05-138 | 20 | Malaysia |
| NAS62323 | 2015-11-317 | 100 | us |
| NAS62323 | 2015-11-316 | 1 | us |
| NAS62323 | 2015-02-42 | 840 | us |
| NAS623-2-3 | 2014-11-317 | 294 | United States |
| NAS623-2-3 | 2014-09-272 | 100 | United States |
| NAS62323 | 2014-04-120 | 226 | US |
| NAS623-2-3 | 2012-11-310 | 877 | |
| NAS62323 | 2012-05-151 | 500 | United States |
| NAS62323 | 2012-04-108 | 100 | CA |
| NAS62323 | 2010-08-237 | 2200 | Italy |
| NAS62323 | 2009-05-125 | 1200 | Italy |
| NAS62323 | 2009-04-117 | 1400 | Italy |
Cross Reference | NSN 5990-00-814-7989
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 455622-1 | 96214 | RAYTHEON COMPANY DBA RAYTHEON |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5990-00-814-7989
Related Products | NSN 5990-00-814-7989
Technical Data | NSN 5990-00-814-7989
| Characteristic | Specifications |
|---|---|
| BODY SIZE | 10 |
| STATOR INPUT VOLTAGE RATING IN VOLTS | 10.2 NOMINAL |
| STATOR INPUT CURRENT RATING | 19.5 MILLIAMPERES NOMINAL |
| STATOR INPUT ELECTRICAL POWER RATING | 68.0 MILLIWATTS NOMINAL |
| FREQUENCY IN HERTZ | 400.0 NOMINAL |
| ZRO RESISTANCE IN OHMS | 770.00 NOMINAL |
| PLUS J ZRO REACTANCE IN OHMS | 230.00 NOMINAL |
| ZRS RESISTANCE IN OHMS | 178.00 NOMINAL |
| PLUS J ZRS REACTANCE IN OHMS | 300.00 NOMINAL |
| ZSS RESISTANCE IN OHMS | 1030.00 NOMINAL |
| PLUS J ZSS REACTANCE IN OHMS | 300.00 NOMINAL |
| ROTOR DC RESISTANCE IN OHMS | 560.00 NOMINAL |
| STATOR DC RESISTANCE IN OHMS | 170.00 NOMINAL |
| PHASE SHIFT ANGLE IN DEG | 14.000 INPUT TO OUTPUT NOMINAL |
| MAXIMUM TOTAL NULL VOLTAGE OUTPUT IN MILLIVOLTS PER VOLT | 50.00 |
| ELECTRICAL ERROR ANGULAR RANGE IN MINUTES | -15.0 TO 15.0 |
| ACTUATOR FRICTION TORQUE AT MINUS 55 DEG CELSIUS | 20.00 CENTIMETER-GRAMS MAXIMUM |
| ACTUATOR FRICTION TORQUE AT PLUS 25 DEG CELSIUS | 4.0 CENTIMETER-GRAMS MAXIMUM |
| BODY STYLE | A2 STANDARD ROUND B |
| SHOULDER DIAMETER | 0.8123 INCHES NOMINAL |
| PILOT DIAMETER | 0.5000 INCHES NOMINAL |
| OVERALL LENGTH | 1.6540 INCHES MAXIMUM |
| FLANGE DIAMETER | 0.9370 INCHES NOMINAL |
| FLANGE THICKNESS | 0.0820 INCHES NOMINAL |
| UNDERCUT WIDTH | 0.0620 INCHES NOMINAL |
| PILOT LENGTH | 0.0380 INCHES NOMINAL |
| SHOULDER LENGTH | 0.0430 INCHES NOMINAL |
| MOUNTING SURFACE TO TERMINAL END DISTANCE | 1.2410 INCHES MAXIMUM |
| SHAFT TYPE | ROUND, SLOTTED SINGLE SHAFT |
| SHAFT DIAMETER | 0.0900 INCHES NOMINAL SINGLE SHAFT |
| SHAFT LENGTH | 0.3750 INCHES NOMINAL SINGLE SHAFT |
| SHAFT SLOT DEPTH | 0.0310 INCHES NOMINAL SINGLE SHAFT |
| SHAFT SLOT WIDTH | 0.0310 INCHES NOMINAL SINGLE SHAFT |
| TERMINAL TYPE AND QUANTITY | 5 WIRE LEAD |
| TERMINAL LOCATION | REAR |
| BODY MATERIAL | STEEL, CORROSION RESISTING |
Restrictions/Controls & Freight Information | NSN 5990-00-814-7989
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 093486 | BOLTS,NUTS OR SCREWS, NOI (SUB 3) |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 713 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5990-00-814-7989
Army
Air Force
Navy| Category | Code | Description |
|---|---|---|
| Materiel Category and Inventory Manager | T | Industrial Supplies (DLA/GSA Items) |
| Appropriation and Budget Activity | 2 | Stock Fund Secondary Items |
| Management Inventory Segment | 2 | NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable. |
| Specific Group/Generic Code | B | Rotary Wing Aircraft |
| Weapons Systems/End Item or Homogeneous Group | BX | OH-58D Army Helicopter Improvement Program (AHIP) |
| Accounting Requirements Code | X | Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DA | Department of the Army |
| Service Organization | A | U.S. Army |
| Reparability | Z | This is a nonreparable item. If condemned or economically unserviceable, then dispose at the level authorized replace the item. |
| Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 HD : Each |
| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Materiel Management Aggregation Code | SX | SX:AF SICA RESIDUAL MMAC-OC-ALC |
| Price Validation | V | The current standard price has been validated.
|
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 HD : Each |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 HD : Each |
