NSN 6615-00-159-2298 SBK11AA24G26, SKB11AA24G26, MILC38418
Product Details | DISPLACEMENT GYROSCOPE
6615-00-159-2298 A gyroscope which senses, measures and transmits angular displacement data.
Part Alternates: SBK11AA24G26, SKB11AA24G26, MILC38418, 8KD9AF6, 6615-00-159-2298, 00-159-2298, 6615001592298, 001592298
Instruments and Laboratory Equipment | Automatic Pilot Mechanisms and Airborne Gyro Components
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 66 | 10 JUN 1971 | 00-159-2298 | 20599 ( GYROSCOPE, DISPLACEMENT ) |
Drawings & Photos | NSN 6615-00-159-2298
Demand History | NSN 6615-00-159-2298
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 8KD9AF6 | 2020-09-247 | 1 | United Kingdom |
| 6615-00-159-2298 | 2020-07-199 | 1 | India |
| SBK11AA24G26 | 2020-05-127 | 20 | IN |
| 8KD9AF6 | 2020-03-73 | 1 | United Kingdom |
| 8KD9AF6 | 2019-05-128 | 1 | United States |
| 8KD9AF6 | 2018-12-340 | 1 | United States |
| 8KD9AF6 | 2018-11-323 | 1 | United Kingdom |
| 8KD9AF6 | 2018-10-281 | 1 | United Kingdom |
| 8KD9AF6 | 2018-08-228 | 1 | United States |
| 8KD9AF6 | 2018-08-228 | 1 | United Kingdom |
| 8KD9AF6 | 2018-06-171 | 1 | us |
| 8KD9AF6 | 2018-06-171 | 1 | United States |
| 6615-00-159-2298 | 2018-01-25 | 3 | AR |
| 6615-00-159-2298 | 2018-01-03 | 3 | AR |
| 8KD9AF6 | 2017-12-339 | 1 | United Kingdom |
| 8KD9AF6 | 2017-11-317 | 1 | United States |
| 8KD9AF6 | 2017-11-317 | 1 | United Kingdom |
| 8KD9AF6 | 2017-06-159 | 1 | United Kingdom |
| 8KD9AF6 | 2017-05-151 | 1 | United States |
| 8KD9AF6 | 2017-03-79 | 2 | United States |
| 8KD9AF6 | 2017-03-74 | 2 | United Kingdom |
| 6615-00-159-2298 | 2016-11-314 | 1 | United Kingdom |
| 8KD9AF6 | 2016-10-288 | 3 | United States |
| 6615-00-159-2298 | 2016-10-288 | 1 | United Kingdom |
| 6615-00-159-2298 | 2016-10-288 | 1 | United Kingdom |
| 6615-00-159-2298 | 2016-05-139 | 1 | United Kingdom |
| SBK11AA24G26 | 2014-06-156 | 1 | United States |
| 6615-00-159-2298 | 2010-08-213 | 2 | AR |
| 6615-00-159-2298 | 2009-10-282 | 1 | AR |
Cross Reference | NSN 6615-00-159-2298
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 6615-00-159-2298
Related Products | NSN 6615-00-159-2298
Technical Data | NSN 6615-00-159-2298
| Characteristic | Specifications |
|---|---|
| UNIT TYPE | DIRECTIONAL OR VERTICAL |
| WHEEL POWER METHOD | ELECTRIC |
| CURRENT TYPE | AC |
| VOLTAGE IN VOLTS | 200.0 |
| FREQUENCY IN HERTZ | 400.0 |
| PHASE | THREE |
| FREEDOM AXIS QUANTITY | 3 |
| GIMBAL QUANTITY | 4 |
| AXIS DISPLACEMENT LIMITATION IN DEG | PORM 82 DEG FOR PITCH AXIS |
| DESIGN TYPE | NONCAGEABLE |
| GIMBAL TORQUE APPLICATION METHOD | TORQUE MOTOR |
| TORQUED GIMBAL QUANTITY | 4 |
| SENSING OUTPUT/SIGNAL LEVEL METHOD | SYNCHRO OUTPUT 26V INTERNALLY EXCITED 11.8V OUTPUT |
| INSTRUMENT TYPE | UNFLOATED |
| SHOCK MOUNT | PROVIDED |
| OVERALL LENGTH | 8.270 INCHES NOMINAL |
| OVERALL WIDTH | 6.000 INCHES NOMINAL |
| OVERALL HEIGHT | 6.000 INCHES NOMINAL |
| III FSC APPLICATION DATA | AIRBORNE GYRO COMPONENT |
| MANUFACTURERS CODE | 81349 |
| NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | MILC38418 |
| MANUFACTURERS CODE | 81349 |
| NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | SBK11AA24G26 |
| MANUFACTURERS CODE | 81349 |
| NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | SKB11AA24G26 |
