Product Details | HYBRID RELAY
5945-01-169-8009 A self-contained device that performs the function of opening or closing an electrical circuit in response to electrical changes in an external circuit. It consists of a combination of semiconductor and passive circuit devices, which in turn control an integral electro-magnetic relay. Excludes relays which employ diodes, rectifiers or other passive devices to achieve contact protection or coil modification. Excludes RELAY, SOLID STATE.
Part Alternates: 21435, 21-435, 25016X, 250-16X, 5028646, 5945-01-169-8009, 01-169-8009, 5945011698009, 011698009
Electrical and Electronic Equipment Components | Relays and Solenoids
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 15 JAN 1984 | 01-169-8009 | 31445 ( RELAY, HYBRID ) |
Cross Reference | NSN 5945-01-169-8009
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5945-01-169-8009
Technical Data | NSN 5945-01-169-8009
| Characteristic | Specifications |
|---|---|
| CONTACT ARRANGEMENT | SINGLE POLE, SINGLE THROW, NORMALLY OPEN AND SINGLE POLE, SINGLE THROW, NORMALLY CLOSED |
| SPECIAL FEATURES | 52.380 CU. IN.;MODERATELY RUGGED;INPUT 240 VAC,50-500 HZ;RATED 10 AMPS AT 30 VDC AND 3 AMPS AT 120 VSC;CONTINOUS DUTY;THD STUD TERMINALS;UNDER/OVER VOLTAGE ADJUSTABLE;3.880 IN. LG;3.000 IN. W;4.500 IN. H;FOUR 0.171 IN. DIA MTG HOLES ON 3.500 X 2.750 IN. MTG CTRS |
Restrictions/Controls & Freight Information | NSN 5945-01-169-8009
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 061300 | CIRCUIT BREAKER/SWITCH NOI |
| Less than car load rating | P | 77.5 |
| Less than truck load rating | P | 77.5 |
| Water commodity Code | 72D | unknown |
| Originating Activity Code | TX | Defense Supply Center Columbus Columbus, OH 43218 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
