NSN 5945-01-277-0784 M83726/30-5003S, M83726305003S, C117882
Product Details | HYBRID RELAY
5945-01-277-0784 A self-contained device that performs the function of opening or closing an electrical circuit in response to electrical changes in an external circuit. It consists of a combination of semiconductor and passive circuit devices, which in turn control an integral electro-magnetic relay. Excludes relays which employ diodes, rectifiers or other passive devices to achieve contact protection or coil modification. Excludes RELAY, SOLID STATE.
Part Alternates: M83726/30-5003S, M83726305003S, C117882, C11788-2 , D6020140, D-602-0140 , D6020150, D-602-0150 , MIL-PRF-83726/30, MILPRF8372630, MIL-R-83726/30, MILR8372630, 04EC073001, 04EC073-001 , 5L.4593.007.91 , 5L459300791, 91593304, 5945-01-277-0784, 49-900-3088 , 01-277-0784, 5945012770784, 012770784, 499003088
Electrical and Electronic Equipment Components | Relays and Solenoids
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 17 APR 1988 | 01-277-0784 | 31445 ( RELAY, HYBRID ) |
Drawings & Photos | NSN 5945-01-277-0784
Demand History | NSN 5945-01-277-0784
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| C117882 | 2024-10-303 | 9 | Canada |
| C117882 | 2024-09-246 | 21 | United States |
| 5945-01-277-0784 | 2020-01-30 | 23 | DIBBS |
| D6020140 | 2011-07-194 | 40 | Singapore |
| 5945-01-277-0784 | 2009-07-208 | 18 | DIBBS |
| 5945-01-277-0784 | 2009-03-64 | 18 | DIBBS |
| 5945-01-277-0784 | 2008-12-364 | 8 | DIBBS |
| 5945-01-277-0784 | 2008-07-189 | 14 | DIBBS |
| 5945-01-277-0784 | 2008-05-144 | 8 | DIBBS |
| 5945-01-277-0784 | 2007-08-226 | 13 | DIBBS |
| 5945-01-277-0784 | 2007-06-171 | 5 | DIBBS |
| 5945-01-277-0784 | 2007-05-145 | 4 | DIBBS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5945-01-277-0784
Related Products | NSN 5945-01-277-0784
Technical Data | NSN 5945-01-277-0784
| Characteristic | Specifications |
|---|---|
| CONTACT ARRANGEMENT | DOUBLE POLE, DOUBLE THROW |
| OVERALL LENGTH | 1.698 INCHES MINIMUM AND 1.718 INCHES MAXIMUM |
| OVERALL WIDTH | 1.005 INCHES MINIMUM AND 1.025 INCHES MAXIMUM |
| OVERALL HEIGHT | 0.990 INCHES MINIMUM AND 1.010 INCHES MAXIMUM |
| FEATURES PROVIDED | HERMETICALLY SEALED |
| SPECIAL FEATURES | 10 AMPS RESISTIVE AT 115 VAC AND 28 VDC;8 AMPS INDUCTIVE AT 115 VAC AND 28 VDC;4 AMPS/2 AMPS-BOTH 200 VAC AND 28 VDC;CONTROL VOLTAGE 20-30 VDC;SOLDER LUG TERMINALS;50-500 SEC ADJUSTABLE TIME DELAY ON OPERATE;1.779 CU IN.;THREE 0.150 IN. W MTG SLOTS ON CORNERS OF ISOSCELES TRIANGLE,BASE 0.625 IN.,ALTITUDE 1.446 IN. NOM;WT 0.156 LBS;MODERATELY RUGGED;STORAGE TEMP -55/+125 DEG C |
| SPECIFICATION/STANDARD DATA | 81349-MIL-R-83726/30 GOVERNMENT SPECIFICATION |
| MANUFACTURERS CODE | 81349 |
| NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | MIL-PRF-83726/30 |
| MANUFACTURERS CODE | 81349 |
| DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | M83726/30-5003S |
Restrictions/Controls & Freight Information | NSN 5945-01-277-0784
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 061300 | CIRCUIT BREAKER/SWITCH NOI |
| Less than car load rating | ||
| Less than truck load rating | P | 77.5 |
| Water commodity Code | 72D | unknown |
| Originating Activity Code | TH | Defense Supply Center Columbus Columbus, OH 43215 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
