NSN 5945-00-628-6484 A8466, A-846-6, AE11100299
Product Details | HYBRID RELAY
5945-00-628-6484 A self-contained device that performs the function of opening or closing an electrical circuit in response to electrical changes in an external circuit. It consists of a combination of semiconductor and passive circuit devices, which in turn control an integral electro-magnetic relay. Excludes relays which employ diodes, rectifiers or other passive devices to achieve contact protection or coil modification. Excludes RELAY, SOLID STATE.
Part Alternates: A8466, A-846-6, AE11100299, AE111-002-99, E323E1, E-323E-1, E323E1A, E-323E-1A, E-384, E384, 21545, 21-545, 4047, 483A, 6952241, 695224-1, 77000546001, 77000546-001, 81517030002, 8151703-0002, 5945-00-628-6484, 00-628-6484, 5945006286484, 006286484
Electrical and Electronic Equipment Components | Relays and Solenoids
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1963 | 00-628-6484 | 31445 ( RELAY, HYBRID ) |
