NSN 5307-01-455-0158 J1196P02, 01-455-0158, 014550158
Product Details | LOCKED IN STUD
5307-01-455-0158 A headless fastener externally threaded on both ends with each threaded portion of one but not necessarily the same nominal diameter. It is designed to be locked in place by either a RING, LOCK, SERRATED or a RING, LOCK, KEYED.
Part Alternates: J1196P02, 5307-01-455-0158, 01-455-0158, 5307014550158, 014550158
Hardware and Abrasives | Studs
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 20 APR 1998 | 01-455-0158 | 16012 ( STUD, LOCKED IN ) |
Cross Reference | NSN 5307-01-455-0158
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| J1196P02 | 07482 | GENERAL ELECTRIC COMPANY DBA GE |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5307-01-455-0158
Technical Data | NSN 5307-01-455-0158
| Characteristic | Specifications |
|---|---|
| DISTANCE FROM SERRATED PORTION TO NUT END | 0.438 INCHES NOMINAL |
| DISTANCE FROM SERRATED PORTION TO STUD END | 0.312 INCHES NOMINAL |
| DISTANCE FROM SERRATED PORTION TO END OF STUD THREAD | 0.093 INCHES MAXIMUM |
| NOMINAL THREAD SIZE | 0.312 INCHES STUD THREAD |
| THREAD CLASS | 3A STUD THREAD |
| THREAD QUANTITY PER INCH | 24 STUD THREAD |
Restrictions/Controls & Freight Information | NSN 5307-01-455-0158
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
