NSN 4730-01-070-9596 12268773-1, 01-070-9596, 122687731
Product Details | FLANGE TO TUBE ELBOW
4730-01-070-9596 A fitting that forms an angle of less that 180 degrees (3.141 radians) from the straight flow. It has a flange connection on one end designed to connect with another flange connection, or a compression type mounting pad. The other end has machine threads (straight threads other than pipe or hose series) designed to accommodate a tube, or is unthreaded and designed to accommodate a tube. It may have side and/or heel inlet(s).
Part Alternates: 12268773-1, 4730-01-070-9596, 01-070-9596, 4730010709596, 122687731, 010709596
Pipe, Tubing, Hose, and Fittings | Hose, Pipe, Tube, Lubrication, and Railing Fittings
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 47 | 25 JAN 1979 | 01-070-9596 | 29668 ( ELBOW, FLANGE TO TUBE ) |
Drawings & Photos | NSN 4730-01-070-9596
Demand History | NSN 4730-01-070-9596
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 4730-01-070-9596 | 2023-09-257 | 15 | DIBBS |
| 4730-01-070-9596 | 2023-05-136 | 2 | United States |
| 4730-01-070-9596 | 2017-11-316 | 100 | United States |
| 12268773-1 | 2017-07-192 | 11 | PK |
| 4730-01-070-9596 | 2017-07-192 | 11 | MANUAL |
| 4730-01-070-9596 | 2016-09-258 | 1 | United States |
| 4730-01-070-9596 | 2016-08-221 | 782 | DIBBS |
| 4730-01-070-9596 | 2015-03-76 | 731 | DIBBS |
| 4730-01-070-9596 | 2014-01-08 | 31 | DIBBS |
| 4730-01-070-9596 | 2009-11-334 | 24 | DIBBS |
| 4730-01-070-9596 | 2009-10-294 | 42 | DIBBS |
| 4730-01-070-9596 | 2009-08-224 | 10 | DIBBS |
| 4730-01-070-9596 | 2009-07-210 | 39 | DIBBS |
| 4730-01-070-9596 | 2008-12-366 | 11 | DIBBS |
| 4730-01-070-9596 | 2008-12-357 | 22 | DIBBS |
Cross Reference | NSN 4730-01-070-9596
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 12268773-1 | 19207 | U S ARMY TANK AUTOMOTIVE COMMAND AMSTA-IM-MM |
