Product Details | LINEAR ACTUATING CYLINDER ASSEMBLY

3040-01-370-5486 A cylinder containing a piston and other component parts designed to develop linear motion required to operate a given object(s) with energy generated from either pneumatic or hydraulic pressure(s). See also CYLINDER, ACTUATING, LINEAR. Do not use if a more specific name applies.2041045000011900057Specialized Test and Handling Equipment, Nuclear Ordnance16500058Aircraft Hydraulic, Vacuum, and De-icing System Components30400042Miscellaneous Power Transmission Equipment

Part Alternates: UTTN91008.19, UTTN9100819, 12414617, 3040-01-370-5486, 01-370-5486, 3040013705486, 013705486

Mechanical Power Transmission Equipment | Miscellaneous Power Transmission Equipment

Supply Group (FSG)	NSN Assign.	NIIN	Item Name Code (INC)
30	24 JAN 1993	01-370-5486	31310 ( CYLINDER ASSEMBLY, ACTUATING, LINEAR )
