Product Details | NONMETALLIC SPECIAL SHAPED SECTION

9390-00-060-4654 A structural shape fabricated from nonmetallic material(s) having a peculiar preformed cross-sectional form. It may have a reinforcing agent(s) and backing. Excludes SEAL, NONMETALLIC SPECIAL SHAPED SECTION.

Part Alternates: LS6776, 9390-00-060-4654, 00-060-4654, 9390000604654, 000604654

Nonmetallic Fabricated Materials | Miscellaneous Fabricated Nonmetallic Materials

Supply Group (FSG) NSN Assign. NIIN
93 01 JAN 1963 00-060-4654

Drawings & Photos | NSN 9390-00-060-4654


Demand History | NSN 9390-00-060-4654

Part Number Request Date QTY Origin
9390-00-060-4654 2017-12-338 1 DIBBS
9390-00-060-4654 2017-12-338 3 DIBBS
9390-00-060-4654 2017-11-325 1 DIBBS
9390-00-060-4654 2017-11-325 3 DIBBS
9390-00-060-4654 2017-10-303 12 United States
9390-00-060-4654 2017-10-297 1 US
9390-00-060-4654 2017-10-297 10 US
9390-00-060-4654 2011-10-277 250 United States

Cross Reference | NSN 9390-00-060-4654

Part Number Cage Code Manufacturer
LS6776 98897 LOCKHEED MARTIN CORPORATION DBA LOCKHEED MARTIN AERONAUTICS

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 9390-00-060-4654

Technical Data | NSN 9390-00-060-4654

Characteristic Specifications
CROSS-SECTIONAL SHAPE STYLE C69
OVERALL HEIGHT 0.342 INCHES NOMINAL
OVERALL WIDTH 0.787 INCHES NOMINAL
BASE FLANGE THICKNESS 0.080 INCHES NOMINAL
BASE FLANGE WIDTH 0.620 INCHES NOMINAL
FIRST ANGLE IN DEG 40.0
LENGTH 144.000 INCHES NOMINAL
MATERIAL RUBBER, LAC 23-932, LOCKHEED AIRCRAFT CORP
NONMETALLIC HARDNESS RATING 55.0 MINIMUM SHORE DUROMETER A AND 65.0 MAXIMUM SHORE DUROMETER A
MINIMUM TENSILE STRENGTH 1300 POUNDS PER SQUARE INCH
TEMP RATING -80.0 DEG FAHRENHEIT
ENVIRONMENTAL PROTECTION LOW TEMPERATURE AND WEATHER RESISTANT
REFERENCE NUMBER DIFFERENTIATING CHARACTERISTICS AS DIFFERENTIATED BY LENGTH
MANUFACTURERS CODE 98897
DESIGN CONTROL REFERENCE LS6776
