Product Details | MOTOR FIELD WINDING

6105-00-249-3714 A winding which is a maintenance part for an electric motor.20329200048Engine Electrical System Components, Nonaircraft29250058Engine Electrical System Components, Aircraft Prime Moving61050018Motors, Electrical

Part Alternates: KB701746PC1, 8138835AG1PC1, 8138835ALTG1, 138835AG1, 6105-00-249-3714, 00-249-3714, 6105002493714, 002493714

Electric Wire, and Power and Distribution Equipment | Motors, Electrical

Supply Group (FSG) NSN Assign. NIIN
61 01 JAN 1963 00-249-3714

Cross Reference | NSN 6105-00-249-3714

Part Number Cage Code Manufacturer
138835AG1 01288 GENERAL ELECTRIC CO DIRECT CURRENT MOTOR AND GENERATOR
8138835AG1PC1 01288 GENERAL ELECTRIC CO DIRECT CURRENT MOTOR AND GENERATOR
8138835ALTG1 01288 GENERAL ELECTRIC CO DIRECT CURRENT MOTOR AND GENERATOR
KB701746PC1 01288 GENERAL ELECTRIC CO DIRECT CURRENT MOTOR AND GENERATOR

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 6105-00-249-3714

Technical Data | NSN 6105-00-249-3714

Characteristic Specifications
COIL TYPE AND QUANTITY 2 FLAT
CONDUCTOR TURN QUANTITY 40.00 SINGLE WINDING 6400.00 1ST WINDING 320.00 2ND WINDING
TERMINAL TYPE AND QUANTITY 4 ROUND WIRE LEAD ALL TERMINALS
MANUFACTURERS CODE 01288
DESIGN CONTROL REFERENCE 138835AG1

Restrictions/Controls & Freight Information | NSN 6105-00-249-3714

Category Code Description
Shelf-Life Code:0Nondeteriorative
Hazardous Material Indicator CodeNThere is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials
Demilitarization Code:ANon-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Controlled Inventory Item Code:UUNCLASSIFIED
Precious Metals Indicator Code:UPrecious metal type is unknown
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Category Code Description
NMF Description 061980 FIELD COILS GENERATOR/MOTOR
Less than car load rating
Less than truck load rating P 77.5
Water commodity Code 593 unknown
Originating Activity Code XX
Air Dimension Code A Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity H Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc.
Air Special Handling Z No special handling required.
Special Handling Code 9 unknonwn
HAZMAT
Type of Cargo Z No special type of cargo code applicable

Management | NSN 6105-00-249-3714

Category Code Description
Cognizance Codes9BNavy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Source of SupplySMSDefense Logistics Agency
Enterprise Business Systems
AgencyDNDepartment of the Navy
Service OrganizationNU.S. Navy
Acquisition Advice CodesYTERMINAL ITEM #(NON-STOCKED ITEMS) Future procurement is not authorized. No wholesale stock is available for issue. 1. Requisitions will not be processed to the wholesale manager. 2. Internal Service/agency requisitioning may be continued in accordance with the Service/agency requisitioning policies.
Controlled Item CodeUUNCLASSIFIED
Shelf Life Code0Nondeteriorative
Purchasing QTY
UOM
1
EA : Each
