Product Details | MOTOR FIELD WINDING

6105-00-400-6796 A winding which is a maintenance part for an electric motor.20329200048Engine Electrical System Components, Nonaircraft29250058Engine Electrical System Components, Aircraft Prime Moving61050018Motors, Electrical

Part Alternates: 322723, 32272-3, 6105-00-400-6796, 00-400-6796, 6105004006796, 004006796

Electric Wire, and Power and Distribution Equipment | Motors, Electrical

Supply Group (FSG) NSN Assign. NIIN
61 05 MAR 1969 00-400-6796

Drawings & Photos | NSN 6105-00-400-6796


Demand History | NSN 6105-00-400-6796

Part Number Request Date QTY Origin
6105-00-400-6796 2013-08-219 1 United Kingdom
6105-00-400-6796 2013-07-189 6 United Kingdom

Cross Reference | NSN 6105-00-400-6796

Part Number Cage Code Manufacturer
32272-3 70210 HONEYWELL INTERNATIONAL INC. DBA HONEYWELL

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 6105-00-400-6796

Technical Data | NSN 6105-00-400-6796

Characteristic Specifications
COIL TYPE AND QUANTITY 2 CURVED
COIL INSIDE LENGTH 2.250 INCHES NOMINAL ALL WINDINGS
COIL INSIDE WIDTH 0.312 INCHES NOMINAL ALL WINDINGS
OUTSIDE LENGTH 3.000 INCHES NOMINAL ALL WINDINGS
OUTSIDE WIDTH 2.000 INCHES NOMINAL ALL WINDINGS
CURVATURE RADIUS 0.562 INCHES NOMINAL ALL WINDINGS
INSIDE DIAMETER 0.062 INCHES NOMINAL ALL WINDINGS
TERMINAL TYPE AND QUANTITY 2 ROUND WIRE LEAD 4TH TERMINAL TYPE
MANUFACTURERS CODE 70210
DESIGN CONTROL REFERENCE 32272-3

Restrictions/Controls & Freight Information | NSN 6105-00-400-6796

Category Code Description
Shelf-Life Code:0Nondeteriorative
Hazardous Material Indicator CodeNThere is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials
Demilitarization Code:QStrategic List Item (SLI). Demilitarization not required. SLI are non-MLI(Munitions List Items) controlled by the U.S. Dept. of Commerce through the Export Administration Regulations (EAR) and indicated on the Commerce Control List (CCL). Each CCL entry is preceded by a four-digit Export Control Commerce Control List Item (CCLI) – MUT to the point of scrap required outside the United States. Inside the United States, MUT is required when the DEMIL integrity code (IC) is “3” and MUT is not required when the DEMIL IC is “6.”
Controlled Inventory Item Code:UUNCLASSIFIED
Precious Metals Indicator Code:AItem does not contain precious metal
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Category Code Description
NMF Description 061980 FIELD COILS GENERATOR/MOTOR
Less than car load rating
Less than truck load rating P 77.5
Water commodity Code 658 unknown
Originating Activity Code AX Defense Supply Center Columbus
Columbus, OH 43216-5000
Air Dimension Code A Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity V Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above.
Air Special Handling Z No special handling required.
Special Handling Code 9 unknonwn
HAZMAT
Type of Cargo Z No special type of cargo code applicable

Management | NSN 6105-00-400-6796

Category Code Description
Materiel Category and Inventory ManagerJ Ground Forces Support Materiel (DLA/GSA Items)
Appropriation and Budget Activity2 Stock Fund Secondary Items
Management Inventory Segment2 NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable.
Specific Group/Generic Code0 Medical Materiel
Weapons Systems/End Item or Homogeneous Group00DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
Accounting Requirements CodeX Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items.
Source of SupplySMSDefense Logistics Agency
Enterprise Business Systems
AgencyDADepartment of the Army
Service OrganizationAU.S. Army
ReparabilityZThis is a nonreparable item. If condemned or economically unserviceable, then dispose at the level authorized replace the item.
Acquisition Advice CodesZINSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures.
Controlled Item CodeUUNCLASSIFIED
Shelf Life Code0Nondeteriorative
Purchasing QTY
UOM
1
EA : Each
