NSN 5990-00-951-5114 MILS2070829, MILS20708-29, 18CT4B
Product Details | TRANSMITTER SYNCHRO
5990-00-951-5114 A synchro consisting of a stator and rotor inductively coupled. The electrical output of the stator into a receiver synchro, a control transformer or differential synchro is dependent upon the position of its rotor. Does not include variable resistors, goniometers, variable transformers, or items with dials.
Part Alternates: MILS2070829, MILS20708-29, 18CT4B, 5990-00-951-5114, 00-951-5114, 5990009515114, 009515114
Electrical and Electronic Equipment Components | Synchros and Resolvers
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1962 | 00-951-5114 | 02073 ( SYNCHRO, TRANSMITTER ) |
Drawings & Photos | NSN 5990-00-951-5114
Demand History | NSN 5990-00-951-5114
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 18CT4B | 2019-10-280 | 1 | UK |
| 18CT4B | 2019-02-38 | 1 | US |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5990-00-951-5114
Technical Data | NSN 5990-00-951-5114
| Characteristic | Specifications |
|---|---|
| BODY SIZE | 18 |
| ROTOR INPUT VOLTAGE RATING IN VOLTS | 90.0 NOMINAL |
| FREQUENCY IN HERTZ | 400.0 NOMINAL |
| OVERALL LENGTH | 3.0600 INCHES NOMINAL |
| FLANGE DIAMETER | 1.7500 INCHES NOMINAL |
| SHAFT TYPE | SPLINE SINGLE SHAFT |
| SHAFT DIAMETER | 0.1850 INCHES NOMINAL SINGLE SHAFT |
| SHAFT LENGTH | 0.5000 INCHES NOMINAL SINGLE SHAFT |
| SPLINE TOOTH QUANTITY | 21 SINGLE SHAFT |
| SPLINE TOOTH DIAMETRAL PITCH | 120 SINGLE SHAFT |
| TERMINAL TYPE AND QUANTITY | 6 SCREW |
| NONDEFINITIVE SPEC/STD DATA | 18CT48 TYPE |
| MANUFACTURERS CODE | 81349 |
| NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | MILS20708-29 |
| MANUFACTURERS CODE | 81349 |
| DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | 18CT4B |
Restrictions/Controls & Freight Information | NSN 5990-00-951-5114
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | B | Munitions List Item - Mutilation (MUT) to the point of scrap required. (Formerly: Demilitarization not required. Trade Security Controls (TSCs) required at disposition.) |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
Management | NSN 5990-00-951-5114
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9N | Navy-owned stocks of defense electronic material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | S9E | Defense Supply Center Columbus Columbus, OH 43218 |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | V | TERMINAL ITEM # Identifies items in stock, but future procurement is not authorized. Requisitions may continue to be submitted until stocks are exhausted. Preferred item National Stock Number is normally provided by application of the phrase: When Exhausted Use (NSN). Requisitions will be submitted in accordance with IMM/Service requisitioning procedures as applicable. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
