Product Details | DIFFERENTIAL TRANSMITTER SYNCHRO
5990-00-924-3939 A synchro, the rotor of which is mechanically positioned for modifying electrical angular information, received from a transmitter synchro and transmitting to receiver synchro or control transformer synchro electrical information corresponding to the sum or difference of the electrical input angle and its rotor position angle. Does not include variable resistors, goniometers, variable transformers, or items with dials.
Part Alternates: MILS2070881, MILS20708-81, Q 320 707 002, Q320707002, X40201972, X40-201-972, 11CDX4B, 5990-00-924-3939, 00-924-3939, 5990009243939, 009243939
Electrical and Electronic Equipment Components | Synchros and Resolvers
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 20 JAN 1966 | 00-924-3939 | 02071 ( SYNCHRO, DIFFERENTIAL TRANSMITTER ) |
Drawings & Photos | NSN 5990-00-924-3939
Demand History | NSN 5990-00-924-3939
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5990-00-924-3939 | 2012-03-72 | 26 | United Arab Emirates |
| 11CDX4B | 2011-03-77 | 1 | United States |
| 5990-00-924-3939 | 2010-03-71 | 1 | US |
Cross Reference | NSN 5990-00-924-3939
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 11CDX4B | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| 11CDX4B | K0624 | MUIRHEAD AEROSPACE LTD DBA MUIRHEAD AVIONICS |
| MILS20708-81 | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| Q 320 707 002 | C2463 | RHEINMETALL SOLDIER ELECTRONICS GMB |
| Q 320 707 002 | S3092 | RHEINMETALL AIR DEFENCE AG |
| X40-201-972 | S3712 | BAE SYSTEMS BOFORS AB |
| X40-201-972 | S3715 | BOFORS AB |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5990-00-924-3939
Related Products | NSN 5990-00-924-3939
Technical Data | NSN 5990-00-924-3939
| Characteristic | Specifications |
|---|---|
| BODY SIZE | 11 |
| STATOR INPUT VOLTAGE RATING IN VOLTS | 90.0 NOMINAL |
| STATOR INPUT CURRENT RATING | 49.0 MILLIAMPERES MAXIMUM |
| STATOR INPUT ELECTRICAL POWER RATING | 530.0 MILLIWATTS NOMINAL |
| FREQUENCY IN HERTZ | 400.0 NOMINAL |
| ZSO IMPEDANCE MAGNITUDE IN OHMS | 1590.00 MINIMUM AND 2050.00 MAXIMUM |
| ZSO IMPEDANCE ANGLE IN DEG | 79.00 MINIMUM AND 85.00 MAXIMUM |
| ZRS IMPEDANCE MAGNITUDE IN OHMS | 470.00 MINIMUM AND 570.00 MAXIMUM |
| ZRS IMPEDANCE ANGLE IN DEG | 23.00 MINIMUM AND 33.00 MAXIMUM |
| TRANSFORMATION RATIO | 1.154 ROTOR TO STATOR NOMINAL |
| PHASE SHIFT ANGLE IN DEG | 4.000 INPUT TO OUTPUT NOMINAL |
| MAXIMUM TEMP RISE | 20.0 DEG CELSIUS |
| MAXIMUM FUNDAMENTAL NULL VOLTAGE IN MILLIVOLTS PER VOLT | 60.00 OUTPUT |
| MAXIMUM TOTAL NULL VOLTAGE OUTPUT IN MILLIVOLTS PER VOLT | 90.00 |
| ELECTRICAL ERROR ANGULAR RANGE IN MINUTES | -7.0 TO 7.0 |
| TORQUE GRADIENT PER ANGULAR DEG | 0.070 INCH-OUNCES MAXIMUM |
| BODY STYLE | A3 STANDARD ROUND C |
| SHOULDER DIAMETER | 0.9995 INCHES MINIMUM AND 1.0000 INCHES MAXIMUM |
| PILOT DIAMETER | 0.6245 INCHES MINIMUM AND 0.6250 INCHES MAXIMUM |
| OVERALL LENGTH | 2.4130 INCHES NOMINAL |
| FLANGE DIAMETER | 1.0570 INCHES MINIMUM AND 1.0620 INCHES MAXIMUM |
| FLANGE THICKNESS | 0.0930 INCHES NOMINAL |
| UNDERCUT DIAMETER | 0.9370 INCHES NOMINAL |
| UNDERCUT WIDTH | 0.0620 INCHES NOMINAL |
| PILOT LENGTH | 0.0620 INCHES NOMINAL |
| SHOULDER LENGTH | 0.0620 INCHES NOMINAL |
| MOUNTING SURFACE TO TERMINAL END DISTANCE | 1.8510 INCHES NOMINAL |
| ALIGNMENT HOLE DEPTH | 0.1250 INCHES MINIMUM |
| ALIGNMENT HOLE BOLT CIRCLE DIAMETER | 0.8120 INCHES NOMINAL |
| ALIGNMENT HOLE QUANTITY | 4 |
| SHAFT TYPE | SPLINE W/THREADS SINGLE SHAFT |
| SHAFT DIAMETER | 0.1870 INCHES MINIMUM AND 0.1872 INCHES MAXIMUM SINGLE SHAFT |
| SHAFT LENGTH | 0.5620 INCHES NOMINAL SINGLE SHAFT |
| SHAFT THREAD LENGTH | 0.1900 INCHES NOMINAL SINGLE SHAFT |
| SPLINE TOOTH QUANTITY | 21 SINGLE SHAFT |
| SPLINE TOOTH DIAMETRAL PITCH | 120 SINGLE SHAFT |
| SHAFT THREAD SERIES DESIGNATOR | UNF SINGLE SHAFT |
| SHAFT NOMINAL THREAD SIZE | 0.1900 INCHES SINGLE SHAFT |
| SHAFT THREAD DIRECTION | RIGHT-HAND SINGLE SHAFT |
| TERMINAL TYPE AND QUANTITY | 6 SCREW |
| TERMINAL LOCATION | REAR |
| BODY MATERIAL | STEEL, STAINLESS |
| TEST DATA DOCUMENT | 81349-MILS20708 SPECIFICATION AND 81349-MILS20708/81 SPECIFICATION |
| MANUFACTURERS CODE | 81349 |
