NSN 5985-01-127-6844 CU-2265/APG-65, CU2265APG65, 10134403
Product Details | DIRECTIONAL COUPLER
5985-01-127-6844 An item specifically designed to be inserted into a transmission line, waveguide or coaxial transmission line to provide a suitable test outlet. The test signal is attenuated to a predetermined value.
Part Alternates: CU-2265/APG-65, CU2265APG65, 10134403 , 410D912001, 410D91200-1, 74870101101, 74-870101-101, 5985-01-127-6844, 01-127-6844, 5985011276844, 011276844
Electrical and Electronic Equipment Components | Antennas, Waveguides, and Related Equipment
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 05 MAR 1982 | 01-127-6844 | 00384 ( COUPLER, DIRECTIONAL ) |
Demand History | NSN 5985-01-127-6844
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 74-870101-101 | 2016-10-296 | 42 | |
| 5985-01-127-6844 | 2016-10-295 | 42 | NECO |
| 5985-01-127-6844 | 2010-04-109 | 3 | DIBBS |
| 5985-01-127-6844 | 2007-04-106 | 6 | DIBBS |
| 5985-01-127-6844 | 2007-03-79 | 6 | DIBBS |
Cross Reference | NSN 5985-01-127-6844
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 410D91200-1 | 25223 | SENSOR AND ANTENNA SYSTEMS, LANSDALE, INC. |
| 410D91200-1 | 66544 | CONTINENTAL MICROWAVE AND TOOL CO., INC. |
| 410D91200-1 | 82152 | L-3 COMMUNICATIONS CORPORATION DBA DATRON ADVANCED TECHNOLOGIES |
| 74-870101-101 | 76823 | NORTHROP GRUMMAN SYSTEMS CORPORATION DIV NORTHROP GRUMMAN AEROSPACE |
| CU-2265/APG-65 | 80058 | JOINT ELECTRONICS TYPE DESIGNATION SYSTEM |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5985-01-127-6844
Related Products | NSN 5985-01-127-6844
Technical Data | NSN 5985-01-127-6844
| Characteristic | Specifications |
|---|---|
| UNIT TYPE | TRANSMISSION LINE |
| RADIO FREQUENCY RATING | NOT RATED |
| DESIGN TYPE | UNIDIRECTIONAL |
| POWER LOSS IN DECIBELS | NOT RATED |
| TERMINAL FITTING NAME | TNC FEMALE CONNECTOR |
| TERMINAL FITTING USAGE DESIGN | ANY ACCEPTABLE |
| OVERALL LENGTH | 4.250 INCHES MAXIMUM |
| OVERALL WIDTH | 3.950 INCHES NOMINAL |
| OVERALL HEIGHT | 0.600 INCHES NOMINAL |
Restrictions/Controls & Freight Information | NSN 5985-01-127-6844
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | P | Munitions List Item. Demilitarization required. Security classified item - Declassification and any additional demilitarization and removal of any sensitive markings or information will be accomplished prior to accountability or physical transfer to a DRMO. This code will not be assigned to AEDA items. |
| Controlled Inventory Item Code: | B | CONFIDENTIAL - RESTRICTED DATA/  |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 061520 | COUPLINGS CONDUIT CAST IRON |
| Less than car load rating | ||
| Less than truck load rating | P | 77.5 |
| Water commodity Code | 72D | unknown |
| Originating Activity Code | TX | Defense Supply Center Columbus Columbus, OH 43218 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | C | Chemical corps items and all other chemicals not covered in other classifications. When chemical item (as indicated by the DOT Proper Shipping Name) is sensitive as defined in Appendix A Section I of DoD 4500.32-R, Volume 1, second position must be from table 85, part 1. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5985-01-127-6844
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 1R | Aeronautical, photographic, and meteorological material (consumable or expense type material) Naval Inventory Control Point, Philadelphia |
| Source of Supply | NRP | NAVICP-ERP 700 Robbins Avenue Philadelphia, PA 19111-5098 |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Reparability | M | Medium Demand Velocity Items (consumables) |
| Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
| Controlled Item Code | B | CONFIDENTIAL - RESTRICTED DATA |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
