Product Details | TRANSMISSION LINE COUPLER
5985-01-038-9274 A coupler which permits the passage of electrical energy in either direction between a balanced and an unbalanced transmission line. See also COUPLER, ROTARY, RADIO FREQUENCY.
Part Alternates: AMC0058, AMC-0058, 138C580H01, 5985-01-038-9274, 01-038-9274, 5985010389274, 010389274
