NSN 5985-00-108-4989 161814-003, 201573, 20157-3
Product Details | TRANSMISSION LINE COUPLER
5985-00-108-4989 A coupler which permits the passage of electrical energy in either direction between a balanced and an unbalanced transmission line. See also COUPLER, ROTARY, RADIO FREQUENCY.
Part Alternates: 161814-003, 201573, 20157-3, 20206369, 2020-6369, 2035636900, 2035-6369-00, 101641, 10164-1, 5985-00-108-4989, 00-108-4989, 5985001084989, 001084989, 161814003
Electrical and Electronic Equipment Components | Antennas, Waveguides, and Related Equipment
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 24 DEC 1972 | 00-108-4989 | 00372 ( COUPLER, TRANSMISSION LINE ) |
Drawings & Photos | NSN 5985-00-108-4989
Demand History | NSN 5985-00-108-4989
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 101641 | 2009-01-06 | 3 | Singapore |
| 101641 | 2008-12-354 | 3 | Singapore |
| 101641 | 2008-12-347 | 3 | Singapore |
Cross Reference | NSN 5985-00-108-4989
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 10164-1 | 06424 | ALLIANT TECHSYSTEMS OPERATIONS LLC DIV DEFENSE ELECTRONIC SYSTEMS |
| 161814-003 | 81413 | BAE SYSTEMS INFORMATION AND ELECTRONIC SYSTEMS INTEGRATION I |
| 20157-3 | 96341 | COBHAM ELECTRONIC SYSTEMS INC. DBA COBHAM DEFENSE ELECTRONICS |
| 2020-6369 | 26805 | TYCO ELECTRONICS CORP |
| 2035-6369-00 | 96341 | COBHAM ELECTRONIC SYSTEMS INC. DBA COBHAM DEFENSE ELECTRONICS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5985-00-108-4989
Related Products | NSN 5985-00-108-4989
Technical Data | NSN 5985-00-108-4989
| Characteristic | Specifications |
|---|---|
| UNIT TYPE | TRANSMISSION LINE |
| RADIO FREQUENCY RATING | 12.4 GIGAHERTZ MINIMUM AND 18.0 GIGAHERTZ MAXIMUM |
| VOLTAGE STANDING WAVE RATIO AT REFERENCE FREQUENCY | 1.35 TO 1 AT 12.4 TO 18 GHZ |
| INPUT IMPEDANCE RATING IN OHMS | 50.0 |
| OUTPUT IMPEDANCE RATING IN OHMS | 50.0 |
| MATERIAL | METAL |
| OVERALL LENGTH | 1.280 INCHES NOMINAL |
| OVERALL WIDTH | 1.080 INCHES NOMINAL |
| OVERALL HEIGHT | 0.375 INCHES NOMINAL |
| III UNPACKAGED UNIT WEIGHT | 0.930 OUNCES |
Restrictions/Controls & Freight Information | NSN 5985-00-108-4989
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 062820 | RADIO/TV TRANSMIT/RECEIVE SETS |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 72D | unknown |
| Originating Activity Code | TX | Defense Supply Center Columbus Columbus, OH 43218 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
