NSN 5985-00-552-8165 VH106A, VH-106-A, 6158373
Product Details | TRANSMISSION LINE COUPLER
5985-00-552-8165 A coupler which permits the passage of electrical energy in either direction between a balanced and an unbalanced transmission line. See also COUPLER, ROTARY, RADIO FREQUENCY.
Part Alternates: VH106A, VH-106-A, 6158373, 615837-3, 2093, 5985-00-552-8165, 00-552-8165, 5985005528165, 005528165
Electrical and Electronic Equipment Components | Antennas, Waveguides, and Related Equipment
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1963 | 00-552-8165 | 00372 ( COUPLER, TRANSMISSION LINE ) |
Drawings & Photos | NSN 5985-00-552-8165
Cross Reference | NSN 5985-00-552-8165
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5985-00-552-8165
Related Products | NSN 5985-00-552-8165
Technical Data | NSN 5985-00-552-8165
| Characteristic | Specifications |
|---|---|
| UNIT TYPE | COAXIAL LINE |
| RADIO FREQUENCY RATING | 108.0 MEGAHERTZ MINIMUM AND 122.0 MEGAHERTZ MAXIMUM |
| INPUT IMPEDANCE RATING IN OHMS | 50.0 |
| OUTPUT IMPEDANCE RATING IN OHMS | 50.0 |
| MATERIAL | BRASS |
| OVERALL LENGTH | 4.062 INCHES NOMINAL |
| OVERALL WIDTH | 2.938 INCHES NOMINAL |
| OVERALL HEIGHT | 2.062 INCHES NOMINAL |
| MOUNTING CONFIGURATION | 4 MTG HOLES 0.204 IN. DIA ON 3 IN. BY 2.50 IN. MTG CENTERS |
