NSN 5985-01-017-0967 010170967
Product Details | RADIO FREQUENCY REFLECTION ISOLATOR
5985-01-017-0967 A device which allows radio frequency energy to pass in one direction with very little power loss, but blocks the flow of energy in the other direction by means of multiple WAVE-polarization or an integral dissipative load. It isolates frequency sensitive circuity from the effects of reflected radio frequency energy resulting from component mismatch. It usually has one or more ports terminated with coaxial connector(s) and/or waveguide flange(s); or other electrical terminations. Isolators designed for internal use in waveguide runs may consist of rods, rings, chips, strips and the like and have no ports or terminations. See also DIPLEXER; DUPLEXER. Excludes CIRCULATOR, RADIO FREQUENCY.
Part Alternates: 010170967
Communication, Detection, and Coherent Radiation Equipment | Miscellaneous Communication Equipment
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 58 | 01-017-0967 | 20347 ( ISOLATOR, RADIO FREQUENCY REFLECTION ) |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5985-01-017-0967
Technical Data | NSN 5985-01-017-0967
| Characteristic | Specifications |
|---|---|
| FREQUENCY RANGE RATING | 4400.0 TO 5000.0 MEGAHERTZ |
| OVERALL LENGTH | 17.570 INCHES NOMINAL |
| OVERALL WIDTH | 4.000 INCHES NOMINAL |
| OVERALL HEIGHT | 4.000 INCHES NOMINAL |
| FLANGE QUANTITY | 3 |
| FLANGE TYPE | CONTACT |
| FLANGE CONNECTION FACILITY QUANTITY | 8 16 |
| FLANGE CONNECTING HOLE DIAMETER | 0.147 INCHES NOMINAL 0.160 INCHES MAXIMUM |
| FLANGE CONNECTING HOLE THREAD SIZE | 10-32 0.138-32 |
| FLANGE CONNECTING HOLE SPACING | FIRST FLANGE HAS 2 HOLES ON EA SIDE SPACED ON 2.430 AND 1.430 IN HOLECTRS,OTHER HAVE 8 THD HOLES SPACED EQUALLY ALONG A 3.250 IN. DIA CIRCLE,8 THD HOLES,2 ON EA SIDE OF RECT OPNGSPACED 2.430 AND 1.430 IN. APART |
| LENGTH | 2.781 INCHES NOMINAL |
| WIDTH | 1.781 INCHES NOMINAL |
| DIAMETER | 3.730 INCHES NOMINAL |
| ANGULAR DISPLACEMENT BETWEEN FLANGE CONTACT SURFACES IN DEG | 180.0 |
| SPECIAL FEATURES | CONSISTS OF A 20 DB,THREE PORT CIRCULATOR WITH A STRAIGHT LENGTH OF WAVEGUIDE |
| MANUFACTURERS CODE | 13499 |
| DESIGN CONTROL REFERENCE | 632-2572-002 |
Restrictions/Controls & Freight Information | NSN 5985-01-017-0967
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
