NSN 5985-01-053-6200 C95384, C9538-4 , CA21037CL4R

Product Details | RADIO FREQUENCY REFLECTION ISOLATOR

5985-01-053-6200 A device which allows radio frequency energy to pass in one direction with very little power loss, but blocks the flow of energy in the other direction by means of multiple WAVE-polarization or an integral dissipative load. It isolates frequency sensitive circuity from the effects of reflected radio frequency energy resulting from component mismatch. It usually has one or more ports terminated with coaxial connector(s) and/or waveguide flange(s); or other electrical terminations. Isolators designed for internal use in waveguide runs may consist of rods, rings, chips, strips and the like and have no ports or terminations. See also DIPLEXER; DUPLEXER. Excludes CIRCULATOR, RADIO FREQUENCY.

Part Alternates: C95384, C9538-4 , CA21037CL4R, CA21037CL-4R , ICS7665, ICS-7665, RR4040CL4, RR4040CL-4 , 1200014, 120001-4 , 30003, 3D01644, 3D0164-4 , 8221651, 822165-1, 5985-01-053-6200, 01-053-6200, 5985010536200, 010536200

Electrical and Electronic Equipment Components | Antennas, Waveguides, and Related Equipment

Supply Group (FSG)	NSN Assign.	NIIN	Item Name Code (INC)
59	07 JAN 1978	01-053-6200	20347 ( ISOLATOR, RADIO FREQUENCY REFLECTION )
