NSN 5985-00-145-3480 2553Q, 26189, 2-6189
Product Details | COAXIAL CRYSTAL MIXER
5985-00-145-3480 An item consisting of coaxial line and associated connectors having two frequency inputs, a crystal (any semiconductor device that provides rectification) and an output connection. It is employed to mix two frequencies, with the resultant output frequency being a composite of the two inputs. For items utilizing electron tube(s) and/or WAVEGUIDE ASSEMBLY, see MIXER STAGE, FREQUENCY; and MIXER, CRYSTAL, WAVEGUIDE.
Part Alternates: 2553Q, 26189, 2-6189, 5985-00-145-3480, 00-145-3480, 5985001453480, 001453480
Electrical and Electronic Equipment Components | Antennas, Waveguides, and Related Equipment
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 29 AUG 1971 | 00-145-3480 | 22970 ( MIXER, CRYSTAL, COAXIAL ) |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5985-00-145-3480
Technical Data | NSN 5985-00-145-3480
| Characteristic | Specifications |
|---|---|
| FREQUENCY RANGE RATING | 8.0 TO 12.0 GIGAHERTZ |
| CRYSTAL NOMINAL CURRENT RATING IN MILLIAMPERES | ANY ACCEPTABLE |
| INSERTION LOSS IN DECIBELS | ANY ACCEPTABLE |
| SIGNAL INPUT TERMINAL DESIGNATOR | NO SIGNAL INPUT TERMINAL DESIGNATOR |
| LOCAL OSCILLATOR INPUT TERMINAL DESIGNATOR | NO LOCAL OSCILLATOR INPUT TERMINAL DESIGNATOR |
| SIGNAL OUTPUT TERMINAL DESIGNATOR | NO SIGNAL OUTPUT TERMINAL DESIGNATOR |
| LOCAL OSCILLATOR INPUT ADJUSTABILITY | NONADJUSTABLE |
| OVERALL LENGTH | 4.453 INCHES NOMINAL |
| OVERALL WIDTH | 1.375 INCHES NOMINAL |
