NSN 5935-00-847-7631 GC816AB1, GL0516, 40176940701
Product Details | ELECTRICAL RECEPTACLE CONNECTOR
5935-00-847-7631 An electrical fitting with electrical contacts constructed to be affixed to the end of a cable, conduit, coaxial line, cord, wire (includes printed/etched), PRINTED WIRING BOARD, or the like for convenience in joining with another electrical connector(s) or PRINTED WIRING BOARD. It is designed to be mounted on a bulkhead, chassis, panel, wall, PRINTED WIRING BOARD, or the like. Excludes LAMPHOLDER; JACK, TELEPHONE; JACK, TIP; INSERT ELECTRICAL CONNECTOR; INSERT MODULE, ELECTRICAL CONNECTOR; CONNECTOR BODY (as modified) and SOCKET, PLUG-IN ELECTRONIC COMPONENTS. See also WIRING HARNESS (as modified) and CABLE ASSEMBLY (as modified). For items with termination wires of more than four inches in length, see LEAD ASSEMBLY, ELECTRICAL. For items without inserts, see SHELL, ELECTRICAL CONNECTOR.
Part Alternates: GC816AB1, GL0516, 40176940701, 4017694-0701, 4700, 5185, 5935-00-847-7631, 00-847-7631, 5935008477631, 008477631
Electrical and Electronic Equipment Components | Connectors, Electrical
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1960 | 00-847-7631 | 15093 ( CONNECTOR, RECEPTACLE, ELECTRICAL ) |
Drawings & Photos | NSN 5935-00-847-7631
Demand History | NSN 5935-00-847-7631
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 4700 | 2019-02-43 | 6 | US |
| 5935-00-847-7631 | 2017-02-44 | 89 | DIBBS |
| 5935-00-847-7631 | 2017-02-33 | 89 | DIBBS |
Cross Reference | NSN 5935-00-847-7631
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 4017694-0701 | 06845 | RAYTHEON COMPANY DBA RAYTHEON |
| 4700 | 71183 | BRYANT ELECTRIC |
| 4700 | 74545 | HUBBELL INC WIRING DEVICE DIV |
| 5185 | 75582 | LEVITON MANUFACTURING CO., INC. DBA LEVITON |
| GC816AB1 | 26512 | NORTHROP GRUMMAN SYSTEMS CORPORATION DIV NORTHROP GRUMMAN AEROSPACE |
| GL0516 | 41326 | GENERAL ELECTRIC CO WIRING DEVICE DEPT |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5935-00-847-7631
Related Products | NSN 5935-00-847-7631
Technical Data | NSN 5935-00-847-7631
| Characteristic | Specifications |
|---|---|
| BODY STYLE | 9K STRAIGHT SHAPE DUPLEX |
| OVERALL HEIGHT | 1.218 INCHES NOMINAL |
| OVERALL WIDTH | 1.500 INCHES NOMINAL |
| CONNECTOR LOCKING METHOD | CONTACT TWISTLOCK |
| POLARIZATION METHOD | CONTACT |
| MATING END QUANTITY | 2 |
| CONTACT POSITION ARRANGEMENT STYLE | ADDT 3 SINGLE MATING END |
| INSERT MATERIAL | PLASTIC ALL MATING ENDS |
| CONTACT REMOVABILITY | REMOVABLE ALL MATING ENDS ALL CONTACT GROUPINGS |
| CONTACT MAXIMUM CURRENT RATING IN AMPS | 15.0 ALL MATING ENDS ALL CONTACT GROUPINGS |
| CONTACT MAXIMUM DC VOLTAGE RATING IN VOLTS | 125.0 ALL MATING ENDS ALL CONTACT GROUPINGS |
| CONTACT MATERIAL | COPPER ALLOY ALL MATING ENDS ALL CONTACT GROUPINGS |
| TERMINAL TYPE | SCREW ALL MATING ENDS ALL CONTACT GROUPINGS |
| TERMINAL LOCATION | BACK ALL MATING ENDS ALL CONTACT GROUPINGS |
Restrictions/Controls & Freight Information | NSN 5935-00-847-7631
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 061680 | ELEC WIRING PLUGS ETC |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 658 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
