NSN 5910-01-234-8308 AN745A, AN7-45A , CFR12RRA473FM
Product Details | PAPER-PLASTIC DIELECTRI METALLIZED FIXED CAPACITOR
5910-01-234-8308 A capacitor whose capacitance value cannot be adjusted or varied having paper, plastic, or any combination of paper and plastic as the dielectric material with a metallic film deposited thereon. It may be a single unit or consist of two or more units which cannot be separated.
Part Alternates: AN745A, AN7-45A , CFR12RRA473FM, MIL-C-55514/8, MILC555148, 5910-01-234-8308, 01-234-8308, 5910012348308, 012348308
Electrical and Electronic Equipment Components | Capacitors
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 21 JUN 1986 | 01-234-8308 | 31959 ( CAPACITOR, FIXED, METALLIZED, PAPER-PLASTIC DIELECTRIC ) |
Drawings & Photos | NSN 5910-01-234-8308
Demand History | NSN 5910-01-234-8308
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| AN745A | 2018-12-338 | 84 | us |
| AN745A | 2017-04-110 | 2769 | United States |
| AN745A | 2014-08-218 | 15 | Serbia |
| AN7-45A | 2014-05-142 | 100 | United States |
| AN7-45A | 2013-08-235 | 5 | US |
| AN745A | 2008-10-296 | 240 | Malaysia |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5910-01-234-8308
Related Products | NSN 5910-01-234-8308
Technical Data | NSN 5910-01-234-8308
| Characteristic | Specifications |
|---|---|
| CAPACITANCE VALUE PER SECTION | 0.047 MICROFARADS SINGLE SECTION |
| TOLERANCE RANGE PER SECTION | -1.00 TO 1.00 PERCENT SINGLE SECTION |
| NONDERATED CONTINUOUS VOLTAGE RATING AND TYPE PER SECTION | 50.0 DC SINGLE SECTION |
| NONDERATED OPERATING TEMP | -55.0 DEG CELSIUS MINIMUM AND 85.0 DEG CELSIUS MAXIMUM |
| BODY STYLE | 27A W/O MTG FACILITIES TERMINAL(S) ON ONE SURFACE |
| BODY LENGTH | 0.190 INCHES NOMINAL |
| BODY WIDTH | 0.200 INCHES NOMINAL |
| BODY HEIGHT | 0.090 INCHES NOMINAL |
| SCHEMATIC DIAGRAM DESIGNATOR | 1C NO COMMON OR GROUNDED ELECTRODE(S) |
| TERMINAL TYPE AND QUANTITY | 2 UNINSULATED WIRE LEAD |
| TERMINAL LENGTH | 1.250 INCHES MINIMUM |
| TERMINAL DIAMETER | 0.025 INCHES NOMINAL |
| CENTER TO CENTER DISTANCE BETWEEN TERMINALS PARALLEL TO LENGTH | 0.200 INCHES NOMINAL |
| CASE MATERIAL | PLASTIC |
| INSULATION RESISTANCE AT REFERENCE TEMP | 500000.0 MEGOHMS |
| DISSIPATION FACTOR AT REFERENCE TEMP IN PERCENT | 0.300 |
| RELIABILITY INDICATOR | ESTABLISHED |
| RELIABILITY FAILURE RATE LEVEL IN PERCENT | 1.000 |
| TEST DATA DOCUMENT | 81349-MIL-C-55514 SPECIFICATION |
| SPECIFICATION/STANDARD DATA | 81349-MIL-C-55514/8 GOVERNMENT SPECIFICATION |
| III TERMINAL SURFACE TREATMENT | SOLDER |
| (NON-CORE DATA) OVERALL LENGTH | 0.190 INCHES NOMINAL |
| III INSULATION RESISTANCE AT MAXIMUM OPERATING TEMP | 70000.0 MEGOHMS |
| (NON-CORE DATA) OVERALL HEIGHT | 0.090 INCHES NOMINAL |
| (NON-CORE DATA) OVERALL WIDTH | 0.245 INCHES NOMINAL |
| MANUFACTURERS CODE | 81349 |
| DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | CFR12RRA473FM |
| MANUFACTURERS CODE | 81349 |
| NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | MIL-C-55514/8 |
