NSN 5342-01-210-6154 MILM17508, MIL-M-17508, 1385778
Product Details | WEAPON SYSTEM RESILIENT MOUNT
5342-01-210-6154 An item made of material having elastic properties. It may have rigid mounting facilities such as a flange(s), sleeve(s), stud(s) or the like. It is designed to isolate or dampen shock and/or vibration of a continuous or intermittent origin and serve as a support for a weapon system component to be isolated. Excludes MOUNT, RESILIENT, UTILITY; SPRING (as modified); BUMPER, NONMETALLIC; BUMPER, RUBBER; BUSHING, NONMETALLIC; hydraulic and pneumatic shock absorbers, dash-pots, grommets, and shock pads.
Part Alternates: MILM17508, MIL-M-17508, 1385778, 3111413, 31114-13, 6E100NM, 6E100NMVM, 5342-01-210-6154, 01-210-6154, 5342012106154, 012106154
Hardware and Abrasives | Hardware, Weapon System
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 14 JUN 1985 | 01-210-6154 | 53589 ( MOUNT, RESILIENT, WEAPON SYSTEM ) |
Drawings & Photos | NSN 5342-01-210-6154
Demand History | NSN 5342-01-210-6154
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| MILM17508 | 2022-05-151 | 4 | US |
| 5342-01-210-6154 | 2020-10-281 | 50 | DIBBS |
| 5342-01-210-6154 | 2020-08-217 | 16 | DIBBS |
| 5342-01-210-6154 | 2020-07-205 | 7 | DIBBS |
| 5342-01-210-6154 | 2020-07-203 | 17 | DIBBS |
| 5342-01-210-6154 | 2020-05-140 | 27 | DIBBS |
| 5342-01-210-6154 | 2020-03-86 | 21 | DIBBS |
| 5342-01-210-6154 | 2019-12-337 | 24 | DIBBS |
| 5342-01-210-6154 | 2018-09-266 | 16 | DIBBS |
| 5342-01-210-6154 | 2018-05-133 | 15 | DIBBS |
| 5342-01-210-6154 | 2016-04-98 | 10 | DIBBS |
| 5342-01-210-6154 | 2016-03-82 | 55 | DIBBS |
| 5342-01-210-6154 | 2014-11-330 | 54 | DIBBS |
| 5342-01-210-6154 | 2014-08-217 | 32 | DIBBS |
| 5342-01-210-6154 | 2014-07-196 | 11 | DIBBS |
| 5342-01-210-6154 | 2014-04-105 | 15 | DIBBS |
| 5342-01-210-6154 | 2013-05-126 | 3 | DIBBS |
| 5342-01-210-6154 | 2012-10-303 | 45 | DIBBS |
| 5342-01-210-6154 | 2011-10-278 | 32 | DIBBS |
| 5342-01-210-6154 | 2011-09-245 | 15 | DIBBS |
| 5342-01-210-6154 | 2010-08-235 | 11 | DIBBS |
| 5342-01-210-6154 | 2010-07-211 | 26 | DIBBS |
| 5342-01-210-6154 | 2010-07-190 | 17 | DIBBS |
| 5342-01-210-6154 | 2008-03-81 | 9 | DIBBS |
Cross Reference | NSN 5342-01-210-6154
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 1385778 | 80064 | NAVAL SHIP SYSTEMS COMMAND |
| 31114-13 | 81860 | BARRY WRIGHT CORPORATION DBA BARRY CONTROLS |
| 6E100NM | 80064 | NAVAL SHIP SYSTEMS COMMAND |
| 6E100NM | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| 6E100NMVM | 03950 | NAVAL INVENTORY CONTROL POINT MECHANICSBURG |
| MIL-M-17508 | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5342-01-210-6154
Restrictions/Controls & Freight Information | NSN 5342-01-210-6154
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | T | 84 months |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 093600 | BRACKETS/BUSHINGS/JOINTS/MOUNTS ETC |
| Less than car load rating | Q | 70 |
| Less than truck load rating | Q | 70.0 |
| Water commodity Code | 713 | unknown |
| Originating Activity Code | HD | Naval Inventory Control Point Mechanicsburg, PA 17055-0788 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5342-01-210-6154
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Special Material ID | VM | Equipment and/or parts requiring special material control and quality assurance which support the non-magnetic signature of minesweepers. |
| Special Material Content | Y | Non-Magnetic (must remain free of strong magnetic field) |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | T | 84 months |
| Purchasing | QTY UOM |
1 EA : Each |
