NSN 5315-01-643-0863 03A259424, 03A259-4-2-4 , 01-643-0863
Product Details | POWER ACTUATED DRIVE PIN
5315-01-643-0863 An item designed to fasten metal, wood, composition material and the like to concrete, masonry, metal, and wood, with power provided from a cartridge (powder), compressed gas, pneumatic and/or hydraulic power. Excludes items that have the actuating media as an integral part of the pin.
Part Alternates: 03A259424, 03A259-4-2-4 , 5315-01-643-0863, 01-643-0863, 5315016430863, 016430863
Hardware and Abrasives | Nails, Machine Keys, and Pins
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 2015078 | 01-643-0863 | 42304 ( PIN, DRIVE, POWER ACTUATED ) |
Drawings & Photos | NSN 5315-01-643-0863
Demand History | NSN 5315-01-643-0863
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 03A259424 | 2019-06-175 | 3 | United States |
| 5315-01-643-0863 | 2018-04-115 | 5 | US |
| 5315-01-643-0863 | 2016-01-27 | 24 | DIBBS |
| 5315-01-643-0863 | 2015-10-302 | 24 | DIBBS |
| 5315-01-643-0863 | 2015-08-228 | 625 | DIBBS |
| 5315-01-643-0863 | 2015-04-92 | 625 | DIBBS |
| 03A259424 | 2010-06-154 | 10 | United States |
| 03A259424 | 2010-06-153 | 10 | US |
| 03A259424 | 2008-05-144 | 5 | US |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5315-01-643-0863
Related Products | NSN 5315-01-643-0863
Technical Data | NSN 5315-01-643-0863
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL COMP 302 OR |
| MATERIAL DOCUMENT AND CLASSIFICATION | AMS QQ-S-763 ASSN STD SINGLE MATERIAL RESPONSE OVERALL |
| SURFACE TREATMENT | PASSIVATE OVERALL |
| SURFACE TREATMENT DOCUMENT AND CLASSIFICATION | ASTM A967 ASSN STD SINGLE TREATMENT RESPONSE OVERALL |
| STYLE DESIGNATOR | GUIDED OR POWDER ACTUATED |
| SHANK LENGTH | 0.750 INCHES NOMINAL |
| WASHER OUTSIDE DIAMETER | 0.506 INCHES NOMINAL |
| SHANK DIAMETER | 0.2490 INCHES MINIMUM AND |
| OVERALL LENGTH | 1.155 INCHES NOMINAL |
| MATERIAL THICKNESS | 0.125 INCHES NOMINAL |
| SHANK LENGTH UNDER WASHER | 0.500 INCHES NOMINAL |
| THREAD SERIES DESIGNATOR | UNJF |
| NOMINAL THREAD SIZE | 0.250 INCHES |
| THREAD CLASS | 3A |
| THREAD DIRECTION | RIGHT-HAND |
| THREAD LENGTH | 0.405 INCHES NOMINAL |
| MATERIAL FOR WHICH DESIGNED | STEEL |
| SPECIAL FEATURES | SEE DRAWING FOR FURTHER DETAILS |
| III END ITEM IDENTIFICATION | B-2 BOMBER |
| III PART NAME ASSIGNED BY CONTROLLING AGENCY | RELAY PANEL 12 GUIDE PIN, PIN REAR MOUNTING |
Restrictions/Controls & Freight Information | NSN 5315-01-643-0863
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 105840 | NAILS/SPIKES I/S NOI PLAIN ETC |
| Less than car load rating | ||
| Less than truck load rating | U | 50.0 |
| Water commodity Code | 594 | unknown |
| Originating Activity Code | GX | HQ Defense Logistics Agency, Enterprise Business Systems Fort Belvoir, VA 22060 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5315-01-643-0863
Air Force| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
