NSN 5315-01-033-4311 53041, 01-033-4311, 010334311
Product Details | QUICK RELEASE PIN
5315-01-033-4311 A headed fastening device having a solid cylindrical or tubular body with retaining ball or pinlike detent(s). The detent(s) is/are positioned and actuated by means of a spring, elastomer or plunger. Plunger may be operated by thumb, cam or other means. May be furnished with a pull ring, pull and/or lock ring, attaching ring or hook.
Part Alternates: 53041, 5315-01-033-4311, 01-033-4311, 5315010334311, 010334311
Hardware and Abrasives | Nails, Machine Keys, and Pins
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 06 JAN 1977 | 01-033-4311 | 08323 ( PIN, QUICK RELEASE ) |
Drawings & Photos | NSN 5315-01-033-4311
Demand History | NSN 5315-01-033-4311
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 53041 | 2024-10-291 | 20 | DIBBS |
| 53041 | 2022-11-312 | 31 | DIBBS |
| 5315-01-033-4311 | 2013-09-253 | 1 | DIBBS-RFPs |
| 53041 | 2012-04-117 | 15 | us |
Cross Reference | NSN 5315-01-033-4311
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 53041 | 84256 | AVIBANK MFG., INC. |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5315-01-033-4311
Related Products | NSN 5315-01-033-4311
Technical Data | NSN 5315-01-033-4311
| Characteristic | Specifications |
|---|---|
| MATERIAL | ALUMINUM ALLOY 413.0 OR ALUMINUM ALLOY A380.0 OR ALUMINUM ALLOY 360.0 OR ALUMINUM ALLOY A413.0 OR ALUMINUM ALLOY 380.0 OR ALUMINUM ALLOY B443.0 OR ALUMINUM ALLOY 518.0 OR ALUMINUM ALLOY A360.0 OR ALUMINUM ALLOY A384.0 HANDLE STEEL SHANK STEEL COMP 440C DETENT ALUMINUM ALLOY 2017 BUTTON STEEL RING STEEL COMP 316 SPRING |
| MATERIAL DOCUMENT AND CLASSIFICATION | QQ-P-591 FED SPEC SINGLE MATERIAL RESPONSE HANDLE AMS 5629,84256 ASSN STD SINGLE MATERIAL RESPONSE SHANK QQ-S-763,CLASS 440C FED SPEC SINGLE MATERIAL RESPONSE DETENT QQ-A-225/5,ALLOY 2017 FED SPEC SINGLE MATERIAL RESPONSE BUTTON |
| SURFACE TREATMENT | ANODIZE OR PASSIVATE HANDLE ANODIZE OR PASSIVATE SHANK ANODIZE OR PASSIVATE DETENT ANODIZE OR PASSIVATE BUTTON ANODIZE OR PASSIVATE RING |
| SURFACE TREATMENT DOCUMENT AND CLASSIFICATION | MIL-A-8625 MIL SPEC 1ST TREATMENT RESPONSE OR QQ-P-35 FED SPEC 2ND TREATMENT RESPONSE HANDLE MIL-A-8625 MIL SPEC 1ST TREATMENT RESPONSE OR QQ-P-35 FED SPEC 2ND TREATMENT RESPONSE SHANK MIL-A-8625 MIL SPEC 1ST TREATMENT RESPONSE OR QQ-P-35 FED SPEC 2ND TREATMENT RESPONSE DETENT MIL-A-8625 MIL SPEC 1ST TREATMENT RESPONSE OR QQ-P-35 FED SPEC 2ND TREATMENT RESPONSE BUTTON MIL-A-8625 MIL SPEC 1ST TREATMENT RESPONSE OR QQ-P-35 FED SPEC 2ND TREATMENT RESPONSE RING |
| HARDNESS RATING | 58.0 ROCKWELL C MINIMUM AND 62.0 ROCKWELL C MAXIMUM OVERALL |
| SHEAR STRENGTH | 50000 DOUBLE POUNDS PER SQUARE INCH |
| STYLE DESIGNATOR | Q244 L HANDLE |
| SHANK DIAMETER | 0.624 INCHES NOMINAL |
| GRIP LENGTH | 2.820 INCHES NOMINAL |
| SHOULDER TO HEAD END DISTANCE | 1.820 INCHES NOMINAL |
| PIN CENTER TO HANDLE END DISTANCE | 2.500 INCHES NOMINAL |
| DETENT TO TAPERED END DISTANCE | 0.650 INCHES NOMINAL |
| ACTUATION TYPE | PUSH |
| ACTUATION METHOD | PUSH BUTTON |
Restrictions/Controls & Freight Information | NSN 5315-01-033-4311
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 105000 | DOWEL PINS I/S NOI IN BAG/BBL/BOXES |
| Less than car load rating | Q | 70 |
| Less than truck load rating | Q | 70.0 |
| Water commodity Code | 576 | unknown |
| Originating Activity Code | SE | San Antonio Air Logistics Center Kelly AFB, TX 78241-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | Z | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5315-01-033-4311
Air Force
Navy| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Materiel Management Aggregation Code | SX | SX:AF SICA RESIDUAL MMAC-OC-ALC |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
