NSN 5315-00-616-5527 MS21261R606, MS21261-R606 , MS3575612
Product Details | WOODRUFF KEY
5315-00-616-5527 An item in the form of a segment of a disk, which may have a flat bottom, with or without projecting shoulders, designed to fit into a keyway in an axle or shaft, and into a matching slot in the hub or boss of a wheel, gear or pulley.
Part Alternates: MS21261R606, MS21261-R606 , MS3575612, MS35756-12 , MS3575618, MS35756-18, AN280606, AN280-606 , ASME B-17.2-606 , ASMEB172606, B1413146, B14131-46 , HGR50ISO108, HGR50-ISO-10-8 , S-316 , ISO108, ISO-10-8 , PL4416-121H FIND NO. 66 , PL4416121HFINDNO66, R103B46, D1413146, D14131-46 , 5H2671 , 5HB88, 606 , 69550, 6J606 , 70009, 7220T , 72A, 905123 , 92269, 977388 , 10077 , 106751, 124549 , 1550100426, 1612 , 1B8708, 21110009, 211-10009 , 23A9C609, 23A9-C-609 , 296205, 29620-5 , 2BA433 , 31954, 357653S , 3790, 4520630, 452-0630 , 501110, 5011-10 , S316, 99510007, 9W00DRUFF, 5315-00-616-5527, 00-616-5527, 5315006165522 , 5315006165527, 9951.0007 , 006165527
Hardware and Abrasives | Nails, Machine Keys, and Pins
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 21 DEC 1966 | 00-616-5527 | 02380 ( KEY, WOODRUFF ) |
Drawings & Photos | NSN 5315-00-616-5527
Demand History | NSN 5315-00-616-5527
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5315-00-616-5527 | 2023-12-363 | 997 | DIBBS |
| 5315-00-616-5527 | 2023-12-354 | 997 | DIBBS |
| 5315-00-616-5527 | 2023-05-122 | 50 | Turkey |
| MS3575612 | 2023-04-103 | 50 | Turkey |
| MS3575612 | 2022-12-335 | 3 | GU |
| MS3575612 | 2021-05-125 | 14 | United States |
| MS35756-12 | 2020-07-184 | 50 | CA |
| MS35756-12 | 2019-03-74 | 50 | Canada |
| 5315-00-616-5522 | 2018-04-94 | 50 | United States |
| MS3575612 | 2018-01-16 | 20 | United States |
| 92269 | 2017-08-216 | 2 | United States |
| MS35756-12 | 2014-03-78 | 230 | United States |
| MS35756-12 | 2014-03-71 | 115 | United States |
| AN280-606 | 2013-08-229 | 880 | Canada |
| MS35756-12 | 2012-02-47 | 100 | Costa Rica |
| MS3575612 | 2008-07-200 | 200 | US |
| 5315-00-616-5522 | 2008-06-165 | 250 | US |
Cross Reference | NSN 5315-00-616-5527
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 5315006165527 | SCY13 | E.C.A ETABLISSEMENT CENTRALD'APPROVISIONNEMENT DES |
| 69550 | D9182 | BOSCH REXROTH GMBH LOHMANN +STOLTERFOHT |
| MS35756-18 | 80205 | NATIONAL AEROSPACE STANDARDS COMMITTEE AEROSPACE INDUSTRIES |
| MS35756-18 | 96906 | MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5315-00-616-5527
Related Products | NSN 5315-00-616-5527
Technical Data | NSN 5315-00-616-5527
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL COMP 8630 OVERALL |
| HARDNESS RATING | 40.0 ROCKWELL C MINIMUM AND 50.0 ROCKWELL C MAXIMUM OVERALL |
| STYLE DESIGNATOR | C55 ROUND BOTTOM |
| CIRCLE DIAMETER | 0.990 INCHES MINIMUM AND 1.000 INCHES MAXIMUM |
| THICKNESS | 0.312 INCHES MINIMUM AND 0.313 INCHES MAXIMUM |
| KEY HEIGHT | 0.433 INCHES MINIMUM AND 0.438 INCHES MAXIMUM |
| STARTING EDGE SHAPE | STRAIGHT |
| KEY SIZE DESIGNATION | WOODRUFF B |
