NSN 5315-00-230-6250 AN280H204, AN280H609, 1
Product Details | WOODRUFF KEY
5315-00-230-6250 An item in the form of a segment of a disk, which may have a flat bottom, with or without projecting shoulders, designed to fit into a keyway in an axle or shaft, and into a matching slot in the hub or boss of a wheel, gear or pulley.
Part Alternates: AN280H204, AN280H609, 1, 204, 205216, 20521-6, 5315-00-230-6250, 00-230-6250, 5315002306250, 002306250
Hardware and Abrasives | Nails, Machine Keys, and Pins
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 01 JAN 1963 | 00-230-6250 | 02380 ( KEY, WOODRUFF ) |
Drawings & Photos | NSN 5315-00-230-6250
Demand History | NSN 5315-00-230-6250
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 1 | 2024-09-267 | 1 | us |
| 1 | 2024-07-212 | 1 | US |
| 1 | 2023-11-319 | 1 | US |
| 1 | 2023-11-311 | 1 | United States |
| 1 | 2023-05-137 | 1 | US |
| 204 | 2021-04-96 | 4 | United States |
| 1 | 2020-11-325 | 1 | US |
| 1 | 2019-05-141 | 1 | US |
| 1 | 2019-04-99 | 4 | |
| 204 | 2017-12-355 | 7 | United States |
| 1 | 2016-10-301 | 1 | |
| 1 | 2016-07-209 | 22 | us |
| 1 | 2016-07-209 | 12 | us |
| 1 | 2014-05-136 | 1 | US |
| 1 | 2011-06-160 | 1 | PH |
Cross Reference | NSN 5315-00-230-6250
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 1 | 81130 | WHITNEY CHAIN OPERATION POWER TRANSMISSION DIV DRESSER INDUSTRIES |
| 204 | 80204 | AMERICAN NATIONAL STANDARDS INSTITUTE, INCORPORATED |
| 20521-6 | 06840 | BENDIX CORP THE |
| 20521-6 | 19315 | HONEYWELL INTL INC DEFENSE AVIONICS SYSTEMS FORMER BENDIX NAVIGATION AND |
| AN280H204 | 88044 | AERONAUTICAL STANDARDS GROUP DEPT OF NAVY AND AIR FORCE |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5315-00-230-6250
Technical Data | NSN 5315-00-230-6250
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL COMP 8630 OR STEEL COMP 4037 OVERALL |
| MATERIAL DOCUMENT AND CLASSIFICATION | MIL-S-6050 MIL SPEC SINGLE MATERIAL RESPONSE OR MIL-S-8695 MIL SPEC SINGLE MATERIAL RESPONSE OVERALL |
| HARDNESS RATING | 26.0 ROCKWELL C MINIMUM AND 33.0 ROCKWELL C MAXIMUM OVERALL |
| STYLE DESIGNATOR | C55 ROUND BOTTOM |
| CIRCLE DIAMETER | 0.490 INCHES MINIMUM AND 0.500 INCHES MAXIMUM |
| THICKNESS | 0.0625 INCHES MINIMUM AND 0.0635 INCHES MAXIMUM |
| KEY HEIGHT | 0.198 INCHES MINIMUM AND 0.203 INCHES MAXIMUM |
| STARTING EDGE SHAPE | ROUND |
| STARTING EDGE RADIUS | 0.008 INCHES MINIMUM AND 0.012 INCHES MAXIMUM |
| KEY SIZE DESIGNATION | WOODRUFF 1 |
| MANUFACTURERS CODE | 88044 |
| DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | AN280H204 |
Restrictions/Controls & Freight Information | NSN 5315-00-230-6250
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
