Product Details | TWIST DRILL
5133-01-097-0409 An end cutting tool having two or more cutting edges, and having helical flutes or grooves adjacent thereto for the admission of coolant and the ejection of cuttings or chips. It is used for drilling holes in various materials. Excludes DRILL, MASONRY (as modified); and DRILL,TWIST, BONE. See also DRILL, PIVOT, JEWELER'S and DRILL, HARDENED STEEL, CARBIDE TIPPED.
Part Alternates: MS271872, MS27187-2 , MS27488 , MS2748812, MS27488-12 , MS27488121, MS27488-12-1 , MS27488123, MS27488-12-3 , MS27488A12 , M41CO 8, M41CO8, NAS907 TYFSZ8, NAS907TYFSZ8, AC/13/3/1223 , AC1331223, B84871, GHN20109003, GHN20109-003 , MILC38999, MIL-C-38999 , 7909023-01 , 535530-122 , 78141791, 7814-1791 , 017000663004, 017-000663-004 , 10129616 , 2250072000, 00110940041, 001109-400-41 , 2501322-12 , 2650421004, 265-0421-004 , 3312 8, 33128, 34000430012, 3400-043-0012 , 352250048774 , 35229, 3578841000, 357-8841-000 , 41308, 41885612, 418856-12 , 48222112, 48-2221-12 , 508/4/24755/000 , 508424755000, 5133-01-097-0409, 01-097-0409, 5133010970409, 535530122, 010970409, 250132212, 790902301
Hand Tools | Drill Bits, Counterbores, and Countersinks: Hand and Machine
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 51 | 03 JUL 1980 | 01-097-0409 | 05237 ( DRILL, TWIST ) |
Drawings & Photos | NSN 5133-01-097-0409
Demand History | NSN 5133-01-097-0409
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| MS2748812 | 2024-08-226 | 3 | United States |
| MS2748812 | 2022-05-136 | 9 | United States |
| MS27488-12-3 | 2019-05-130 | 2840 | Turkey |
| MS27488123 | 2018-05-137 | 10 | United States |
| MS27488-12 | 2017-01-09 | 153 | Greece |
| MS27488-12-1 | 2014-01-09 | 100 | US |
| MS27488-12 | 2014-01-07 | 1900 | IL |
| MS2748812 | 2013-09-254 | 4 | US |
| 34000430012 | 2013-03-85 | 30 | us |
| MS27488121 | 2012-10-293 | 2000 | Italy |
| MILC38999 | 2011-12-340 | 50 | China |
| MS2748812 | 2010-08-228 | 50 | Brazil |
| MILC38999 | 2010-03-69 | 10 | United States |
| MILC38999 | 2010-03-68 | 13 | United States |
| MS271872 | 2009-09-265 | 1 | US |
| MS271872 | 2009-02-34 | 240 | United Kingdom |
Cross Reference | NSN 5133-01-097-0409
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5133-01-097-0409
Technical Data | NSN 5133-01-097-0409
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL, COBALT HIGH SPEED OVERALL |
| SURFACE TREATMENT | OXIDE FILM OVERALL |
| HARDNESS RATING | NOT RATED |
| CUTTING END STYLE | 52 GENERAL PURPOSE |
| FLUTE LENGTH | 1.188 INCHES MINIMUM |
| SHANK STYLE | 76 STRAIGHT ROUND |
| SHANK DIAMETER | 0.199 INCHES NOMINAL |
| OVERALL LENGTH | 2.250 INCHES NOMINAL |
| NOMINAL CUTTING DIAMETER | 0.1990 INCHES |
| CUTTING ROTATION DIRECTION | RIGHT-HAND |
| POINT TYPE | SPLIT |
| POINT ANGLE | 135.0 DEGREES NOMINAL |
| FLUTE QUANTITY | 2 |
| SPECIAL FEATURES | SCREW MACHINE LG; WIRE SIZE 8 |
| SPECIFICATION/STANDARD DATA | 80205-NAS907 PROFESSIONAL/INDUSTRIAL ASSOCIATION STANDARD |
| NONDEFINITIVE SPEC/STD DATA | F TYPE |
