Product Details | TWIST DRILL

5133-01-095-4780 An end cutting tool having two or more cutting edges, and having helical flutes or grooves adjacent thereto for the admission of coolant and the ejection of cuttings or chips. It is used for drilling holes in various materials. Excludes DRILL, MASONRY (as modified); and DRILL,TWIST, BONE. See also DRILL, PIVOT, JEWELER'S and DRILL, HARDENED STEEL, CARBIDE TIPPED.

Part Alternates: M41CO 50, M41CO50, NAS907, NAS907 TYCSZ50 , NAS907 TYFSZ50, NAS907TYCSZ50, NAS907TYFSZ50, 3312 50, 331250, 35187, 41350, 5133-01-095-4780, 01-095-4780, 5133010954780, 010954780

Hand Tools | Drill Bits, Counterbores, and Countersinks: Hand and Machine

Supply Group (FSG) NSN Assign. NIIN
51 30 MAY 1980 01-095-4780

Drawings & Photos | NSN 5133-01-095-4780


Cross Reference | NSN 5133-01-095-4780

Part Number Cage Code Manufacturer
3312 50 03882 NEW YORK TWIST DRILL INC
35187 03882 NEW YORK TWIST DRILL INC
41350 16568 PRECISION TWIST DRILL CO
M41CO 50 16568 PRECISION TWIST DRILL CO
NAS907 80205 NATIONAL AEROSPACE STANDARDS COMMITTEE AEROSPACE INDUSTRIES
NAS907 TYCSZ50 80244 GENERAL SERVICES ADMINISTRATION FEDERAL SUPPLY SERVICE

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 5133-01-095-4780

Technical Data | NSN 5133-01-095-4780

Characteristic Specifications
MATERIAL STEEL, COBALT HIGH SPEED OVERALL
SURFACE TREATMENT OXIDE FILM OVERALL
HARDNESS RATING NOT RATED
CUTTING END STYLE 52 GENERAL PURPOSE
FLUTE LENGTH 0.688 INCHES NOMINAL
SHANK STYLE 76 STRAIGHT ROUND
SHANK DIAMETER 0.070 INCHES NOMINAL
OVERALL LENGTH 1.688 INCHES NOMINAL
NOMINAL CUTTING DIAMETER 0.0700 INCHES
CUTTING ROTATION DIRECTION RIGHT-HAND
POINT TYPE SPLIT
POINT ANGLE 135.0 DEGREES NOMINAL
FLUTE QUANTITY 2
SPECIAL FEATURES SCREW MACHINE LG; WIRE SIZE 50
SPECIFICATION/STANDARD DATA 80205-NAS907 PROFESSIONAL/INDUSTRIAL ASSOCIATION STANDARD
NONDEFINITIVE SPEC/STD DATA F TYPE

Restrictions/Controls & Freight Information | NSN 5133-01-095-4780

Category Code Description
Shelf-Life Code:0Nondeteriorative
Hazardous Material Indicator CodeNThere is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials
Demilitarization Code:ANon-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Controlled Inventory Item Code:UUNCLASSIFIED
Precious Metals Indicator Code:AItem does not contain precious metal
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Category Code Description
NMF Description 186620 TOOLS, NOI HAND OTHER THAN POWER
Less than car load rating Q 70
Less than truck load rating W Rating Variable
Water commodity Code 732 unknown
Originating Activity Code ZN Netherlands
ZO
ZP
Air Dimension Code A Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity B Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials.
Air Special Handling Z No special handling required.
Special Handling Code 9 unknonwn
HAZMAT
Type of Cargo Z No special type of cargo code applicable

Management | NSN 5133-01-095-4780

Category Code Description
Budget Code9 General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors.
Fund CodeLPItems initially authorized for local purchase.
Price ValidationN The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
  • The price has not been analyzed or reviewed for accuracy.
  • ZOP or Standard price challenges are permissible, but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of ?L? or?F?,the case must be evaluated locally where purchased or fabricated.
Source of SupplyGSAGeneral Services Administration
Washington, D.C. 20406
AgencyDFDepartment of the Air Force
Service OrganizationFU.S. Air Force
ReparabilityNStock Fund (except Munitions)
Acquisition Advice CodesLLOCAL PURCHASE # (NON-STOCKED ITEMS) Defense Logistics Agency (DLA)/GSA/Service/Agency-managed items authorized for local purchase as normal means of support at base, post, camp or station level. Item not stocked in wholesale distribution system of IMM/Service/Agency ICP.
Controlled Item CodeUUNCLASSIFIED
Shelf Life Code0Nondeteriorative
