Product Details | TWIST DRILL

5133-00-841-8591 An end cutting tool having two or more cutting edges, and having helical flutes or grooves adjacent thereto for the admission of coolant and the ejection of cuttings or chips. It is used for drilling holes in various materials. Excludes DRILL, MASONRY (as modified); and DRILL,TWIST, BONE. See also DRILL, PIVOT, JEWELER'S and DRILL, HARDENED STEEL, CARBIDE TIPPED.

Part Alternates: D1E 26, D1E26, 1727 26, 172726, 4322, 43220147, 4322-0147, 47584, 5740, 70010147, 7001-0147, 7010055, 70-10055, 5133-00-841-8591, 00-841-8591, 5133008418591, 008418591

Hand Tools | Drill Bits, Counterbores, and Countersinks: Hand and Machine

Supply Group (FSG) NSN Assign. NIIN
51 28 DEC 1966 00-841-8591

Drawings & Photos | NSN 5133-00-841-8591


Demand History | NSN 5133-00-841-8591

Part Number Request Date QTY Origin
4322 2014-09-272 1 United States

Cross Reference | NSN 5133-00-841-8591

Part Number Cage Code Manufacturer
1727 26 13130 CLEVELAND TWIST DRILL CO DIV OF GREENFIELD INDUSTRIES INC
1727 26 1NEX4 KENNAMETAL INC. DIV KENNAMETAL INDUSTRIAL PRODUCTS
4322 03882 NEW YORK TWIST DRILL INC
4322-0147 03882 NEW YORK TWIST DRILL INC
47584 13130 CLEVELAND TWIST DRILL CO DIV OF GREENFIELD INDUSTRIES INC
47584 1NEX4 KENNAMETAL INC. DIV KENNAMETAL INDUSTRIAL PRODUCTS
5740 71485 UNION BUTTERFIELD CORP P O BOX 9000 CRYSTAL LAKE IL 60039
70-10055 71485 UNION BUTTERFIELD CORP P O BOX 9000 CRYSTAL LAKE IL 60039
7001-0147 13130 CLEVELAND TWIST DRILL CO DIV OF GREENFIELD INDUSTRIES INC
7001-0147 1NEX4 KENNAMETAL INC. DIV KENNAMETAL INDUSTRIAL PRODUCTS
D1E 26 16568 PRECISION TWIST DRILL CO

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 5133-00-841-8591

Technical Data | NSN 5133-00-841-8591

Characteristic Specifications
MATERIAL CARBIDE OVERALL
HARDNESS RATING NOT RATED
CUTTING END STYLE 52 GENERAL PURPOSE
FLUTE LENGTH 1.375 INCHES NOMINAL
SHANK STYLE 76 STRAIGHT ROUND
SHANK DIAMETER 0.147 INCHES NOMINAL
OVERALL LENGTH 2.500 INCHES NOMINAL
NOMINAL CUTTING DIAMETER 0.1470 INCHES
CUTTING ROTATION DIRECTION RIGHT-HAND
POINT TYPE CONVENTIONAL
POINT ANGLE 118.0 DEGREES NOMINAL
FLUTE QUANTITY 2
SPECIAL FEATURES SOLID CARBIDE; HEAVY DUTY; WIRE SIZE 26

Restrictions/Controls & Freight Information | NSN 5133-00-841-8591

Category Code Description
Hazardous Material Indicator CodeNThere is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials
Demilitarization Code:ANon-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Precious Metals Indicator Code:AItem does not contain precious metal
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
