NSN 5133-00-236-3405 MS1707653, MS17076-53, B94.11M
Product Details | TWIST DRILL
5133-00-236-3405 An end cutting tool having two or more cutting edges, and having helical flutes or grooves adjacent thereto for the admission of coolant and the ejection of cuttings or chips. It is used for drilling holes in various materials. Excludes DRILL, MASONRY (as modified); and DRILL,TWIST, BONE. See also DRILL, PIVOT, JEWELER'S and DRILL, HARDENED STEEL, CARBIDE TIPPED.
Part Alternates: MS1707653, MS17076-53, B94.11M, B9411M, C08897, GGGD751, GGG-D-751, GGG-D-751 TYBCL2, GGGD751TYBCL2, T-102, R51, T102, 950 15/16, 9501516, 08897, 10610, 11560, 120 15/16, 1201516, 1314, 201 15/16, 2011516, 2411 15/16, 24111516, 2510 15/16, 25101516, 25645, 27310, 320, 404, 46160, 4710142, 47-10142, 49760, 510, 51060, 5133-00-236-3405, 00-236-3405, 5133002363405, 002363405
Hand Tools | Drill Bits, Counterbores, and Countersinks: Hand and Machine
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 51 | 01 JAN 1963 | 00-236-3405 | 05237 ( DRILL, TWIST ) |
Drawings & Photos | NSN 5133-00-236-3405
Demand History | NSN 5133-00-236-3405
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| T102 | 2023-06-158 | 1 | US |
| T102 | 2023-04-111 | 1 | US |
| GGGD751 | 2020-04-104 | 1 | US |
| T102 | 2014-06-171 | 1 | Romania |
| 320 | 2014-06-164 | 5 | United States |
| 510 | 2013-09-263 | 8 | US |
| 404 | 2011-10-278 | 8 | US |
| 1314 | 2010-01-05 | 10 | LK |
Cross Reference | NSN 5133-00-236-3405
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 08897 | 13130 | CLEVELAND TWIST DRILL CO DIV OF GREENFIELD INDUSTRIES INC |
| 08897 | 1NEX4 | KENNAMETAL INC. DIV KENNAMETAL INDUSTRIAL PRODUCTS |
| 10610 | 067J8 | MORSE CUTTING TOOLS |
| 10610 | 41672 | MORSE CUTTING TOOLS DIV OF MORSE CUTTING TOOL CORP |
| 11560 | 42970 | LEAR SIEGLER INC NATIONAL TWIST DRILL AND TOOL DIV |
| 120 15/16 | 1NEX4 | KENNAMETAL INC. DIV KENNAMETAL INDUSTRIAL PRODUCTS |
| 120 15/16 | 60NQ9 | GREENFIELD INDUSTRIES, INC. |
| 120 15/16 | 65400 | GREENFIELD INDUSTRIES INC |
| 1314 | 067J8 | MORSE CUTTING TOOLS |
| 1314 | 41672 | MORSE CUTTING TOOLS DIV OF MORSE CUTTING TOOL CORP |
| 201 15/16 | 42970 | LEAR SIEGLER INC NATIONAL TWIST DRILL AND TOOL DIV |
| 2411 15/16 | 03882 | NEW YORK TWIST DRILL INC |
| 2510 15/16 | 13130 | CLEVELAND TWIST DRILL CO DIV OF GREENFIELD INDUSTRIES INC |
| 2510 15/16 | 1NEX4 | KENNAMETAL INC. DIV KENNAMETAL INDUSTRIAL PRODUCTS |
| 2510 15/16 | 60NQ9 | GREENFIELD INDUSTRIES, INC. |
| 25645 | 92061 | BENDIX CORP THE INDUSTRIAL TOOLS DIV SOUTH BELOIT PLANT |
| 27310 | 03882 | NEW YORK TWIST DRILL INC |
| 320 | 82333 | REPUBLIC DRILL AND TOOL CO DIV OF AEW ELECTRIC INC |
| 404 | 84600 | FREY CO INC THE |
| 46160 | 82333 | REPUBLIC DRILL AND TOOL CO DIV OF AEW ELECTRIC INC |
| 47-10142 | 71485 | UNION BUTTERFIELD CORP P O BOX 9000 CRYSTAL LAKE IL 60039 |
| 49760 | 1NEX4 | KENNAMETAL INC. DIV KENNAMETAL INDUSTRIAL PRODUCTS |
| 49760 | 60NQ9 | GREENFIELD INDUSTRIES, INC. |
| 49760 | 65400 | GREENFIELD INDUSTRIES INC |
| 510 | 71485 | UNION BUTTERFIELD CORP P O BOX 9000 CRYSTAL LAKE IL 60039 |
| 51060 | 16568 | PRECISION TWIST DRILL CO |
| 950 15/16 | 13130 | CLEVELAND TWIST DRILL CO DIV OF GREENFIELD INDUSTRIES INC |
| B94.11M | 05047 | AMERICAN SOCIETY OF MECHANICAL ENGINEERS |
| C08897 | 1NEX4 | KENNAMETAL INC. DIV KENNAMETAL INDUSTRIAL PRODUCTS |
| C08897 | 60NQ9 | GREENFIELD INDUSTRIES, INC. |
| GGG-D-751 | 81348 | FEDERAL SPECIFICATIONS PROMULGATED BY GENERAL SERVICES |
| GGG-D-751 TYBCL2 | 80244 | GENERAL SERVICES ADMINISTRATION FEDERAL SUPPLY SERVICE |
| MS17076-53 | 96906 | MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS |
| R51 | 16568 | PRECISION TWIST DRILL CO |
| T-102 | 92061 | BENDIX CORP THE INDUSTRIAL TOOLS DIV SOUTH BELOIT PLANT |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5133-00-236-3405
Related Products | NSN 5133-00-236-3405
Technical Data | NSN 5133-00-236-3405
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL, HIGH SPEED OVERALL |
| HARDNESS RATING | NOT RATED |
| CUTTING END STYLE | 52 GENERAL PURPOSE |
| FLUTE LENGTH | 6.125 INCHES NOMINAL |
| SHANK STYLE | 76 STRAIGHT ROUND |
| SHANK DIAMETER | 0.937 INCHES NOMINAL |
| OVERALL LENGTH | 10.750 INCHES NOMINAL |
| NOMINAL CUTTING DIAMETER | 0.9375 INCHES |
| CUTTING ROTATION DIRECTION | RIGHT-HAND |
| POINT TYPE | CONVENTIONAL |
| POINT ANGLE | 118.0 DEGREES NOMINAL |
| FLUTE QUANTITY | 2 |
| SPECIAL FEATURES | TAPER LG; FRACTIONAL SIZE 15/16 |
| SPECIFICATION/STANDARD DATA | 05047-ASME B94.11M PROFESSIONAL/INDUSTRIAL ASSOCIATION STANDARD |
Restrictions/Controls & Freight Information | NSN 5133-00-236-3405
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 186620 | TOOLS, NOI HAND OTHER THAN POWER |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 732 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5133-00-236-3405
Army
Navy
Marines| Category | Code | Description |
|---|---|---|
| Materiel Category and Inventory Manager | E | General Supplies (DLA/GSA Items) |
| Appropriation and Budget Activity | 2 | Stock Fund Secondary Items |
| Management Inventory Segment | 2 | NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable. |
| Specific Group/Generic Code | 0 | Medical Materiel |
| Weapons Systems/End Item or Homogeneous Group | 00 | DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item |
| Accounting Requirements Code | D | Durable item. An item of Army property coded with an ARC of "D" in the AMDF. Durable items do not require property book accountability after issue from the stock record account, but do require hand receipt control when issued to the user. Commercial and fabricated items similar to items coded ?D?in the AMDF are considered durable items. |
| Source of Supply | GSA | General Services Administration Washington, D.C. 20406 |
| Agency | DA | Department of the Army |
| Service Organization | A | U.S. Army |
| Reparability | Z | This is a nonreparable item. If condemned or economically unserviceable, then dispose at the level authorized replace the item. |
| Acquisition Advice Codes | V | TERMINAL ITEM # Identifies items in stock, but future procurement is not authorized. Requisitions may continue to be submitted until stocks are exhausted. Preferred item National Stock Number is normally provided by application of the phrase: When Exhausted Use (NSN). Requisitions will be submitted in accordance with IMM/Service requisitioning procedures as applicable. |
| Controlled Item Code | M | HANDTOOLS AND SHOP EQUIPMENT |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Stores Account Code | 1 | Marine Corps Stock Fund Account Item. |
| Combat Essentiality Code | 7 | An item that has been reviewed and determined not to fit the definition of codes 0 thru 6. These items are not assigned a specific application within the Marine Corps. |
| Materiel Management Code | 0 | GSA MaterielItems cataloged by the Marine Corps and managed by the General Services Administration. |
| Echelon Management Code | 2 | ICP/DSSC Marine Corps-managed Recoverability Code D items and Defense Logistics Agency (DLA)/TACOM/GSA) items which the integrated manager has not decontrolled. |
| Source of Supply | GSA | General Services Administration Washington, D.C. 20406 |
| Agency | DM | U.S. Marine Corps |
| Service Organization | M | U.S. Marine Corps |
| Reparability | Z | Nonreparable item. When unserviceable, condemn and dispose at the level indicated by the first digit of the maintenance code. |
| Acquisition Advice Codes | V | TERMINAL ITEM # Identifies items in stock, but future procurement is not authorized. Requisitions may continue to be submitted until stocks are exhausted. Preferred item National Stock Number is normally provided by application of the phrase: When Exhausted Use (NSN). Requisitions will be submitted in accordance with IMM/Service requisitioning procedures as applicable. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9Q | Navy-owned stocks of items accepted by the General Services Administration for support of Navy requirements Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | GSA | General Services Administration Washington, D.C. 20406 |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | V | TERMINAL ITEM # Identifies items in stock, but future procurement is not authorized. Requisitions may continue to be submitted until stocks are exhausted. Preferred item National Stock Number is normally provided by application of the phrase: When Exhausted Use (NSN). Requisitions will be submitted in accordance with IMM/Service requisitioning procedures as applicable. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
