NSN 5133-00-224-4029 MS154445, MS15444-5, B94.11M
Product Details | TWIST DRILL
5133-00-224-4029 An end cutting tool having two or more cutting edges, and having helical flutes or grooves adjacent thereto for the admission of coolant and the ejection of cuttings or chips. It is used for drilling holes in various materials. Excludes DRILL, MASONRY (as modified); and DRILL,TWIST, BONE. See also DRILL, PIVOT, JEWELER'S and DRILL, HARDENED STEEL, CARBIDE TIPPED.
Part Alternates: MS154445, MS15444-5, B94.11M, B9411M, DBE77A, GGGD751, GGG-D-751, GGG-D-751 TYC, GGGD751TYC, T-105, R18, T105, 918 77, 91877, 01021, 11355, 13377, 1340, 150 77, 15077, 18077, 2001 77, 200177, 2012-T 77, 2012T77, 20635, 208, 236, 24192, 407, 4110259, 41-10259, 44147, 503-S 77, 503S77, 5133-00-224-4029, 00-224-4029, 5133002244029, 002244029
Hand Tools | Drill Bits, Counterbores, and Countersinks: Hand and Machine
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 51 | 01 JAN 1963 | 00-224-4029 | 05237 ( DRILL, TWIST ) |
Drawings & Photos | NSN 5133-00-224-4029
Demand History | NSN 5133-00-224-4029
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 01021 | 2024-10-288 | 72 | US |
| T105 | 2023-02-51 | 8 | United States |
| 01021 | 2021-12-355 | 1 | Taiwan |
| GGGD751 | 2020-04-104 | 1 | US |
| 208 | 2019-11-312 | 5 | United States |
| 5133-00-224-4029 | 2018-03-82 | 24 | United States |
| T105 | 2017-10-293 | 4 | US |
| R18 | 2016-05-148 | 1 | France |
| 236 | 2015-03-83 | 1 | |
| 236 | 2015-02-52 | 9 | |
| 236 | 2014-12-352 | 9 | |
| 236 | 2014-11-322 | 9 | |
| 236 | 2014-10-296 | 9 | |
| 407 | 2010-03-78 | 1 | US |
Cross Reference | NSN 5133-00-224-4029
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 01021 | 13130 | CLEVELAND TWIST DRILL CO DIV OF GREENFIELD INDUSTRIES INC |
| 11355 | 067J8 | MORSE CUTTING TOOLS |
| 11355 | 41672 | MORSE CUTTING TOOLS DIV OF MORSE CUTTING TOOL CORP |
| 13377 | 42970 | LEAR SIEGLER INC NATIONAL TWIST DRILL AND TOOL DIV |
| 1340 | 067J8 | MORSE CUTTING TOOLS |
| 1340 | 41672 | MORSE CUTTING TOOLS DIV OF MORSE CUTTING TOOL CORP |
| 150 77 | 60NQ9 | GREENFIELD INDUSTRIES, INC. |
| 150 77 | 65400 | GREENFIELD INDUSTRIES INC |
| 18077 | 16568 | PRECISION TWIST DRILL CO |
| 2001 77 | 13130 | CLEVELAND TWIST DRILL CO DIV OF GREENFIELD INDUSTRIES INC |
| 2012-T 77 | 03882 | NEW YORK TWIST DRILL INC |
| 20635 | 03882 | NEW YORK TWIST DRILL INC |
| 208 | 42970 | LEAR SIEGLER INC NATIONAL TWIST DRILL AND TOOL DIV |
| 236 | 71485 | UNION BUTTERFIELD CORP P O BOX 9000 CRYSTAL LAKE IL 60039 |
| 24192 | 92061 | BENDIX CORP THE INDUSTRIAL TOOLS DIV SOUTH BELOIT PLANT |
| 407 | 84600 | FREY CO INC THE |
| 41-10259 | 71485 | UNION BUTTERFIELD CORP P O BOX 9000 CRYSTAL LAKE IL 60039 |
| 44147 | 60NQ9 | GREENFIELD INDUSTRIES, INC. |
| 44147 | 65400 | GREENFIELD INDUSTRIES INC |
| 503-S 77 | 65400 | GREENFIELD INDUSTRIES INC |
| 918 77 | 13130 | CLEVELAND TWIST DRILL CO DIV OF GREENFIELD INDUSTRIES INC |
| B94.11M | 05047 | AMERICAN SOCIETY OF MECHANICAL ENGINEERS |
| DBE77A | 55719 | IDSC HOLDINGS LLC DBA SNAP-ON INDUSTRIAL |
| GGG-D-751 | 81348 | FEDERAL SPECIFICATIONS PROMULGATED BY GENERAL SERVICES |
| GGG-D-751 TYC | 80244 | GENERAL SERVICES ADMINISTRATION FEDERAL SUPPLY SERVICE |
| MS15444-5 | 96906 | MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS |
| R18 | 16568 | PRECISION TWIST DRILL CO |
| T-105 | 92061 | BENDIX CORP THE INDUSTRIAL TOOLS DIV SOUTH BELOIT PLANT |
