NSN 4820-00-822-8046 550985, 00-822-8046, 008228046
Product Details | BUTTERFLY VALVE
4820-00-822-8046 A valve that controls flow by a circular disk, or a pair of semicircular disks, attached to a common spindle or lever turning on a diametral axis.20248100015Valves, Powered48200018Valves, Nonpowered
Part Alternates: 550985, 4820-00-822-8046, 00-822-8046, 4820008228046, 008228046
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 48 | 01 JAN 1962 | 00-822-8046 | 05489 ( VALVE, BUTTERFLY ) |
Drawings & Photos | NSN 4820-00-822-8046
Demand History | NSN 4820-00-822-8046
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 4820-00-822-8046 | 2023-04-118 | 5 | US |
| 4820-00-822-8046 | 2008-05-135 | 3 | United States |
Cross Reference | NSN 4820-00-822-8046
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 550985 | 73030 | HAMILTON SUNDSTRAND CORPORATION |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 4820-00-822-8046
Related Products | NSN 4820-00-822-8046
Technical Data | NSN 4820-00-822-8046
| Characteristic | Specifications |
|---|---|
| STYLE DESIGNATOR | A1A STRAIGHT THRU FLANGED ENDS |
| FACE TO FACE DISTANCE | 1.440 INCHES |
| VALVE OPERATION METHOD | AIR |
| CONNECTION TYPE | FLANGE 1ST END |
| FLANGE SHAPE | RECTANGULAR WITH HOLES 1ST END |
| BOLT HOLE QUANTITY | 4 1ST END |
| BOLT HOLE NOMINAL DIAMETER | 0.190 INCHES 1ST END |
| FLANGE FACE DESIGN | RECESSED STRAIGHT 1ST END |
| RECESS NOMINAL DIAMETER | 1.520 INCHES 1ST END |
| RECESS NOMINAL DEPTH | 0.055 INCHES 1ST END |
| BONNET TYPE | INSIDE SCREW |
| MANUFACTURERS CODE | 73030 |
| DESIGN CONTROL REFERENCE | 550985 |
Restrictions/Controls & Freight Information | NSN 4820-00-822-8046
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | B | Munitions List Item - Mutilation (MUT) to the point of scrap required. (Formerly: Demilitarization not required. Trade Security Controls (TSCs) required at disposition.) |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 127220 | PRESSURE REG/RED/RELIEF VALVES NOI |
| Less than car load rating | ||
| Less than truck load rating | P | 77.5 |
| Water commodity Code | 671 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | ||
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
