NSN 4720-00-307-7994 M38386A1D005, AS38386, AS38386A1D005H
Product Details | AIR DUCT HOSE
4720-00-307-7994 A flexible, tubular item of light wall construction. It must have single or multiple layers of nonmetallic material, but may contain metal wire reinforcement, foil type liner, and/or woven or braided cover. It is designed to convey under low pressure gaseous material, such as air and fumes, and light weight solid materials, such as dust, powders, and fibers. For items with couplings, see HOSE ASSEMBLY, AIR DUCT. For items of sleeve section design rated for high pressure use, see SLEEVE, SEAL, COUPLING. Excludes hose, nonmetallic.
Part Alternates: M38386A1D005, AS38386, AS38386A1D005H, FLX1501128240, FLX1501-128-240, MILD38386, MIL-D-38386, 1885222, 4720-00-307-7994, 00-307-7994, 4720003077994, 003077994
Pipe, Tubing, Hose, and Fittings | Hose and Flexible Tubing
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 47 | 21 OCT 1973 | 00-307-7994 | 11116 ( HOSE, AIR DUCT ) |
Drawings & Photos | NSN 4720-00-307-7994
Demand History | NSN 4720-00-307-7994
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 4720-00-307-7994 | 2013-12-356 | 16 | DIBBS |
| 4720-00-307-7994 | 2013-12-352 | 2 | DIBBS |
Cross Reference | NSN 4720-00-307-7994
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 1885222 | 07076 | LOCKHEED MARTIN CORPORATION DBA LOCKHEED MARTIN SIMULATION |
| 1885222 | 11447 | L-3 COMMUNICATIONS CORPORATION DBA COMMUNICATION SYSTEMS - EAST |
| AS38386 | 81343 | SOCIETY OF AUTOMOTIVE ENGINEERS INC |
| AS38386A1D005H | 81343 | SOCIETY OF AUTOMOTIVE ENGINEERS INC |
| FLX1501-128-240 | 16632 | FLEXFAB, LLC |
| FLX1501128240 | 16632 | FLEXFAB, LLC |
| M38386A1D005 | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| MIL-D-38386 | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 4720-00-307-7994
Technical Data | NSN 4720-00-307-7994
| Characteristic | Specifications |
|---|---|
| MATERIAL | COTTON 1ST PLY COTTON 2ND PLY STEEL REINFORCING WIRE |
| STYLE DESIGNATOR | A4 HELICALLY WOUND CONTINUOUS WIRE SUPPORTED |
| CROSS-SECTIONAL SHAPE STYLE | B3 ROUND |
| INSIDE DIAMETER | 16.000 INCHES NOMINAL FIRST END |
| MEASURING METHOD AND LENGTH | 60.000 INCHES NOMINAL OVERALL |
| CONNECTION TYPE | PLAIN BOTH ENDS |
| FEATURES PROVIDED | THERMAL INSULATED |
| (NON-CORE DATA) TEMP RANGE | -65.0 TO 250.0 DEG FAHRENHEIT |
Restrictions/Controls & Freight Information | NSN 4720-00-307-7994
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 051035 | DUCTS:AIR SYSTEM |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 736 | unknown |
| Originating Activity Code | AX | Defense Supply Center Columbus Columbus, OH 43216-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 4720-00-307-7994
Air Force| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Materiel Management Aggregation Code | SX | SX:AF SICA RESIDUAL MMAC-OC-ALC |
| Price Validation | V | The current standard price has been validated.
|
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
