Product Details | AXIAL PISTONS PUMP

4320-00-647-3295 A positive displacement device which utilizes the reciprocating motion of a multiple number of parallel pistons arranged axially in a cylinder barrel as a means of transferring a liquid from one place to another. The pistons are actuated by revolving the cylinder barrel at an angle to the drive shaft axis or by a tilting box when the cylinder barrel revolves on the drive shaft. The piston displacement may be fixed or variable. It is designed to be driven by a prime mover which is not an integral part of the pump.20216500058Aircraft Hydraulic, Vacuum, and De-icing System Components43200020Power and Hand Pumps

Part Alternates: N14883, 9090883, 4320-00-647-3295, 00-647-3295, 4320006473295, 006473295

Pumps and Compressors | Power and Hand Pumps

Supply Group (FSG) NSN Assign. NIIN
43 01 JAN 1963 00-647-3295

Cross Reference | NSN 4320-00-647-3295

Part Number Cage Code Manufacturer
9090883 18876 U S ARMY AVIATION AND MISSILE COMMAND
N14883 22915 NORTHROP GRUMMAN CORP ELECTRONIC SYSTEMS DEFENSIVE SYSTEM

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 4320-00-647-3295

Technical Data | NSN 4320-00-647-3295

Characteristic Specifications
MAXIMUM DISCHARGE FLOW RATE 5.7 GALLONS PER MINUTE
PUMPING ELEMENT OPERATING POSITION VERTICAL
PUMPING ELEMENT TYPE PISTON

Restrictions/Controls & Freight Information | NSN 4320-00-647-3295

Category Code Description
Hazardous Material Indicator CodeNThere is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials
Demilitarization Code:ANon-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Precious Metals Indicator Code:UPrecious metal type is unknown
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Category Code Description
NMF Description 128000 PUMPS PWR NOI/WORKING HEADS/PARTS
Less than car load rating M 85
Less than truck load rating M 85.0
Water commodity Code 594 unknown
Originating Activity Code XX
Air Dimension Code A Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity V Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above.
Air Special Handling Z No special handling required.
Special Handling Code 9 unknonwn
HAZMAT
Type of Cargo Z No special type of cargo code applicable
