NSN 3040-01-168-0713 642AS04661, 642AS0466-1, 01-168-0713
Product Details | ROTATING SHAFT EYE BRACKET
3040-01-168-0713 A rigid metal item usually fabricated from steel castings and/or welded steel pieces and designed with one or more hole(s) in line to accompany and hold, align, or support a mechanical shaft that rotates through an arc not to exceed 360 degrees (6.282 radians). It may have provision to accommodate a bushing or sleeve but usually it has a straight drilled shaft-support hole. Mounting holes are provided for attaching to a supporting member or main body. Excludes HOUSING, BEARING UNIT (as modified).20411900057Specialized Test and Handling Equipment, Nuclear Ordnance16800049Miscellaneous Aircraft Accessories and Components2590000030400042Miscellaneous Power Transmission Equipment
Part Alternates: 642AS04661, 642AS0466-1, 3040-01-168-0713, 01-168-0713, 3040011680713, 011680713
Mechanical Power Transmission Equipment | Miscellaneous Power Transmission Equipment
Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
---|---|---|---|
30 | 12 DEC 1983 | 01-168-0713 | 22089 ( BRACKET, EYE, ROTATING SHAFT ) |
Cross Reference | NSN 3040-01-168-0713
Part Number | Cage Code | Manufacturer |
---|---|---|
642AS0466-1 | 03TF2 | TRIANGLE TOOL CO |
642AS0466-1 | 27361 | BURKE PRODUCTS, INC. |
642AS0466-1 | 30003 | NAVAL AIR SYSTEMS COMMAND |
642AS0466-1 | 58017 | COBRA INDUSTRIES INC |
642AS0466-1 | 60696 | KRDC INC DBA MARTIN-PALMER TOOL & DIE CO DIV |
642AS0466-1 | 76301 | BOEING COMPANY, THE DBA BOEING |
Request a Quote
What Our Customers Say
Compare
Related Products | NSN 3040-01-168-0713
Technical Data | NSN 3040-01-168-0713
Characteristic | Specifications |
---|---|
MATERIAL | STEEL |
BORE INSIDE DIAMETER | 0.758 INCHES NOMINAL |
OVERALL LENGTH | 3.700 INCHES NOMINAL |
WIDTH | 2.437 INCHES NOMINAL |
OVERALL HEIGHT | 1.350 INCHES NOMINAL |
MOUNTING HOLE TYPE AND QUANTITY | 6 PLAIN |
MOUNTING HOLE NOMINAL DIAMETER | 0.758 INCHES |
SPECIAL FEATURES | BORE CENTERLINE TO BASE BOTTOM IS 0.625IN.; ITEM IS OPPOSITE HAND OR REVERSE SENSE FROM ITEM LISTED UNDER NSN 1420-01-137-4862 |
III END ITEM IDENTIFICATION | HARPOON MISSLE |
Restrictions/Controls & Freight Information | NSN 3040-01-168-0713
Category | Code | Description |
---|---|---|
Shelf-Life Code: | 0 | Nondeteriorative |
Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
Demilitarization Code: | B | Munitions List Item - Mutilation (MUT) to the point of scrap required. (Formerly: Demilitarization not required. Trade Security Controls (TSCs) required at disposition.) |
Controlled Inventory Item Code: | U | UNCLASSIFIED |
Precious Metals Indicator Code: | A | Item does not contain precious metal |
Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
Category | Code | Description |
---|---|---|
NMF Description | 093600 | BRACKETS/BUSHINGS/JOINTS/MOUNTS ETC |
Less than car load rating | ||
Less than truck load rating | Q | 70.0 |
Water commodity Code | 713 | unknown |
Originating Activity Code | TX | Defense Supply Center Columbus Columbus, OH 43218 |
Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
Air Special Handling | Z | No special handling required. |
Special Handling Code | 9 | unknonwn |
HAZMAT | ||
Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 3040-01-168-0713
Category | Code | Description |
---|---|---|
Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
Agency | DN | Department of the Navy |
Service Organization | N | U.S. Navy |
Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
Controlled Item Code | U | UNCLASSIFIED |
Shelf Life Code | 0 | Nondeteriorative |
Purchasing | QTY UOM |
1 EA : Each |
