NSN 3020-01-196-1237 LB106255, LB-106255, LB106257ANDLC106251
Product Details | MATCHED BEVEL GEAR SET
3020-01-196-1237 A grouping of two or more or any combination of GEAR, BEVEL; GEARSHAFT, BEVEL; or GEAR CLUSTER, BEVEL which have been matched together for a given characteristic within a specified tolerance. Includes only those gears designed and tested to accomplish a specifically desired function.
Part Alternates: LB106255, LB-106255, LB106257ANDLC106251, LB-106257ANDLC-106251, LD106250, LD-106250, LJ-106203 PART 21-4, LJ106203PART214, 3020-01-196-1237, 01-196-1237, 3020011961237, 011961237
Mechanical Power Transmission Equipment | Gears, Pulleys, Sprockets, and Transmission Chain
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 30 | 07 DEC 1984 | 01-196-1237 | 21969 ( GEAR SET, BEVEL, MATCHED ) |
Cross Reference | NSN 3020-01-196-1237
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| LB-106255 | 0AT62 | DRESSER-RAND COMPANY DBA RECIPROCATING PRODUCTS DIV |
| LB-106257ANDLC-106251 | 93232 | CURTISS-WRIGHT ELECTRO-MECHANICAL CORPORATION |
| LD-106250 | 0BR59 | DRESSER-RAND COMPANY DBA STEAM TRBINE MTR GENERATOR DIV |
| LD-106250 | 93235 | TURBODYNE DIV OF DRESSER INDUSTRIES INC |
| LJ-106203 PART 21-4 | 0AT62 | DRESSER-RAND COMPANY DBA RECIPROCATING PRODUCTS DIV |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 3020-01-196-1237
Technical Data | NSN 3020-01-196-1237
| Characteristic | Specifications |
|---|---|
| COMPONENT QUANTITY | 2 |
| NONSUPPLY ITEMS AND QUANTITIES | 93232 LB-106257 GEAR 1,93232 LC-106251 GEAR 1 |
Restrictions/Controls & Freight Information | NSN 3020-01-196-1237
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 121870 | GEAR/SPEED INCREASING/REDUCING MACH |
| Less than car load rating | ||
| Less than truck load rating | P | 77.5 |
| Water commodity Code | 593 | unknown |
| Originating Activity Code | AX | Defense Supply Center Columbus Columbus, OH 43216-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 3020-01-196-1237
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 7H | Depot level reparable shipboard and base equipment, assemblies, components and repair parts related to Naval Sea Systems Command equipment Naval Inventory Control Point, Mechanicsburg |
| Issue Repair, or Requisition | BL | Submit/refer requisitions to NAVICP MECH. Centralized control for issue of repair parts for specific programs/equipments. |
| Special Material Content | 9 | Non-Hazardous or Non-Sensitive Item, does not require hazardous or special handling, packaging or precautions |
| Source of Supply | NRP | NAVICP-ERP 700 Robbins Avenue Philadelphia, PA 19111-5098 |
| Agency | DN | Department of the Navy |
| Service Organization | L | Lead Service - 22 (Repairable) |
| Reparability | H | Depot Level Reparable |
| Acquisition Advice Codes | C | SERVICE/AGENCY-MANAGED (Service/Agency use only.) # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by individual Services supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
