NSN 9540-00-595-8622 AMS-QQ-A-200/11, AMSQQA20011, AMSSTD184

Product Details | STRUCTURAL ANGLE

9540-00-595-8622 A structural shape fabricated from a ferrous or nonferrous material and resembling the letter L in cross-sectional form. The edges may have a bulb, be rounded, and the inside corner may have a fillet.20295200017Structural Shapes95400040Structural Shapes, Nonferrous Base Metal

Part Alternates: AMS-QQ-A-200/11, AMSQQA20011, AMSSTD184, AMS-STD-184 , ASTM B221, ASTMB221, DIE 253245 , DIE 60-10340 , DIE 7782 , DIE LS4109 , DIE PA1319 , DIE253245, DIE6010340, DIE7782, DIELS4109, DIEPA1319, LS4109, QQ-A-200/11, QQA20011, 7782, 9540-00-595-8622, 00-595-8622, 9540005958622, 005958622

Metal Bars, Sheets, and Shapes | Structural Shapes, Nonferrous Base Metal

Supply Group (FSG)	NSN Assign.	NIIN	Item Name Code (INC)
95	01 JAN 1961	00-595-8622	37017 ( ANGLE, STRUCTURAL )

Drawings & Photos | NSN 9540-00-595-8622

Part Number	Request Date	QTY	Origin
QQA20011	2020-01-03	1	US
7782	2011-10-285	5	United States
7782	2011-01-25	3	United States
QQA20011	2009-10-287	14	FX

Cross Reference | NSN 9540-00-595-8622

Part Number	Cage Code	Manufacturer
7782	77783	ALCOA/REYNOLDS METALS COMPANY
AMS-QQ-A-200/11	81343	SOCIETY OF AUTOMOTIVE ENGINEERS INC
AMS-STD-184	81343	SOCIETY OF AUTOMOTIVE ENGINEERS INC
ASTM B221	81346	AMERICAN SOCIETY FOR TESTING AND MATERIALS
DIE 253245	01634	ALUMINUM CO OF AMERICA
DIE 60-10340	29321	TRANSTAR METALS CORP
DIE 7782	77783	ALCOA/REYNOLDS METALS COMPANY
DIE LS4109	98897	LOCKHEED MARTIN CORPORATION DBA LOCKHEED MARTIN AERONAUTICS
DIE PA1319	06012	TRANSTAR METALS CORP
LS4109	98897	LOCKHEED MARTIN CORPORATION DBA LOCKHEED MARTIN AERONAUTICS
QQ-A-200/11	81348	FEDERAL SPECIFICATIONS PROMULGATED BY GENERAL SERVICES

Request a Quote

What Our Customers Say

Thank you very much for the excellent service and professional customer care.

Ernie G. Honeywell

The service was excellent. I can think of no improvements to date that you can make regarding internet sales.

John L. Raytheon

The representative for WBParts was efficient & handled our request in a timely & professional manner.

Karen G. General Dynamics

Tried two other sources, neither of them responded, was all done online, never spoke to anyone.

Rex S. US Airforce

The response is quick and the price is often very good. We are completely satisfied.

Patricia S. NASA

Compare

NSNs for Compare ( up to 4 ): Add 9540-00-595-8622

Compare

Related Products | NSN 9540-00-595-8622

9540-00-595-8624, 9540-00-595-8672, 9540-00-595-8674, 9540-00-595-8676, 9540-00-595-8684

Technical Data | NSN 9540-00-595-8622

Characteristic	Specifications
MATERIAL	ALUMINUM ALLOY AMS-QQ-A-200/11, ALLOY 7075
FABRICATION METHOD	EXTRUDED
HEAT TREATMENT	T-6 SOLUTION HEAT TREATED
LENGTH	10.000 FEET MINIMUM AND 12.000 FEET MAXIMUM
BASIC SHAPE STYLE	E5 ANGLE
OVERALL HEIGHT	1.000 INCHES NOMINAL
OVERALL WIDTH	3.000 INCHES NOMINAL
LEFT SIDE FLANGE THICKNESS	0.100 INCHES NOMINAL
FILLET RADIUS WHERE LEFT FLANGE JOINS BASE FLANGE	0.125 INCHES NOMINAL
OUTER RADIUS WHERE LEFT FLANGE JOINS BASE FLANGE	0.031 INCHES NOMINAL
BASE FLANGE THICKNESS	0.093 INCHES NOMINAL
LEFT INSIDE ANGLE	90.0 DEGREES NOMINAL
FIRST TIP STYLE	7 SQUARE WITH INNER AND OUTER CORNER RADII
FIRST TIP INNER RADIUS	0.031 INCHES NOMINAL
FIRST TIP OUTER RADIUS	0.031 INCHES NOMINAL
SECOND TIP RELATIONSHIP TO FIRST TIP	IDENTICAL
WEIGHT PER UNIT MEASURE	0.450 POUNDS PER LINEAR FOOT
NONDEFINITIVE SPEC/STD DATA	ALLOY 7075 AND TEMPER T6

Restrictions/Controls & Freight Information | NSN 9540-00-595-8622

Restrictions
Freight

Category	Code	Description
Shelf-Life Code:	0	Nondeteriorative
Hazardous Material Indicator Code	N	There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials
Demilitarization Code:	A	Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Controlled Inventory Item Code:	U	UNCLASSIFIED
Precious Metals Indicator Code:	A	Item does not contain precious metal
Criticality Code:	X	The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Automatic Data Processing Equipment:	0	Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9)

Category	Code	Description
NMF Description	013140	ALUMINUM ANGLES
Less than car load rating
Less than truck load rating	S	60.0
Water commodity Code	576	unknown
Originating Activity Code	XX
Air Dimension Code	A	Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity	B	Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials.
Air Special Handling	Z	No special handling required.
Special Handling Code	R	unknonwn
HAZMAT
Type of Cargo	Z	No special type of cargo code applicable

Management | NSN 9540-00-595-8622

Air Force
Navy

Category	Code	Description
Budget Code	9	General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors.
Fund Code	SF	Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point.
Price Validation	V	The current standard price has been validated. The item has been analyzed in conjunction with the Zero Overpricing Program and is in the accepted price range. The item was procured under open competition and under the competitive arena the price is considered fair and reasonable. ZOP or Standard price challenges are permissible but must be supported by adequate justification.
Source of Supply	SMS	Defense Logistics Agency Enterprise Business Systems
Agency	DF	Department of the Air Force
Service Organization	F	U.S. Air Force
Reparability	N	Stock Fund (except Munitions)
Acquisition Advice Codes	Z	INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures.
Controlled Item Code	U	UNCLASSIFIED
Shelf Life Code	0	Nondeteriorative
Purchasing	QTY UOM	1 FT : Foot

Category	Code	Description
Cognizance Codes	9B	Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg
Source of Supply	SMS	Defense Logistics Agency Enterprise Business Systems
Agency	DN	Department of the Navy
Service Organization	N	U.S. Navy
Acquisition Advice Codes	Z	INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures.
Controlled Item Code	U	UNCLASSIFIED
Shelf Life Code	0	Nondeteriorative
Purchasing	QTY UOM	1 FT : Foot
