NSN 9330-01-180-0253 LP535, L-P-535, 01-180-0253
Product Details | PLASTIC SHEET
9330-01-180-0253 A cellular, solid, or laminated material including film furnished in widths greater than 6 inches (152.4mm). It includes material cut to specific lengths. It may include fillers, reinforcements, or pigments. For items which have a definite rated electrical characteristics, see INSULATION SHEET, ELECTRICAL. Excludes CELLOPHANE; DRY TRANSFER SHEET; PLASTIC SHEET, LAMINATED, DECORATIVE; PLASTIC STRIP; SCREEN, COLOR OVERLAY; TILE, VINYL RESIN; PLASTIC SHEET, TRACING.
Part Alternates: LP535, L-P-535, 9330-01-180-0253, 01-180-0253, 9330011800253, 011800253
Nonmetallic Fabricated Materials | Plastics Fabricated Materials
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 93 | 23 MAY 1984 | 01-180-0253 | 18304 ( PLASTIC SHEET ) |
Drawings & Photos | NSN 9330-01-180-0253
Demand History | NSN 9330-01-180-0253
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| LP535 | 2013-09-270 | 1 | US |
Cross Reference | NSN 9330-01-180-0253
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| L-P-535 | 81348 | FEDERAL SPECIFICATIONS PROMULGATED BY GENERAL SERVICES |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 9330-01-180-0253
Related Products | NSN 9330-01-180-0253
Technical Data | NSN 9330-01-180-0253
| Characteristic | Specifications |
|---|---|
| MATERIAL | PLASTIC,L-P-535,COMP B,TYPE I,CLASS 2 |
| NONMETALLIC HARDNESS RATING | NOT RATED |
| MINIMUM TENSILE STRENGTH | 6800 POUNDS PER SQUARE INCH |
| FLEXURAL STRENGTH | NOT RATED |
| FABRICATION METHOD | SOLID |
| MATERIAL TRANSPARENCY | CLEAR |
| LENGTH | 72.000 INCHES MINIMUM AND 72.250 INCHES MAXIMUM |
| WIDTH | 20.000 INCHES MINIMUM AND 20.250 INCHES MAXIMUM |
| THICKNESS | 0.040 INCHES NOMINAL |
| SPECIAL FEATURES | HIGH POLISH FINISH; HIGH CHEMICAL RESISTANT |
| NONDEFINITIVE SPEC/STD DATA | B COMPOSITION AND I TYPE AND 2 CLASS |
| MANUFACTURERS CODE | 81348 |
| NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | L-P-535 |
Restrictions/Controls & Freight Information | NSN 9330-01-180-0253
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 156300 | PLASTIC SHEET/PLATE NOI |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 772 | unknown |
| Originating Activity Code | CX | Defense Supply Center Richmond Richmond, VA 23297-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 9330-01-180-0253
Air Force
Navy| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 SH : Sheet |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
Z SH : Sheet |
