NSN 9330-01-027-6143 MARGARD MR-5000, MARGARDMR5000, TUFFAK CM2
Product Details | PLASTIC SHEET
9330-01-027-6143 A cellular, solid, or laminated material including film furnished in widths greater than 6 inches (152.4mm). It includes material cut to specific lengths. It may include fillers, reinforcements, or pigments. For items which have a definite rated electrical characteristics, see INSULATION SHEET, ELECTRICAL. Excludes CELLOPHANE; DRY TRANSFER SHEET; PLASTIC SHEET, LAMINATED, DECORATIVE; PLASTIC STRIP; SCREEN, COLOR OVERLAY; TILE, VINYL RESIN; PLASTIC SHEET, TRACING.
Part Alternates: MARGARD MR-5000, MARGARDMR5000, TUFFAK CM2, TUFFAKCM2, LEXAN MR-4000, LEXANMR10112CLEAR, LEXANMR4000, 9330GSC125, 9330-GSC125, 9330-01-027-6143, 01-027-6143, 9330010276143, 010276143
Nonmetallic Fabricated Materials | Plastics Fabricated Materials
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 93 | 19 SEP 1976 | 01-027-6143 | 18304 ( PLASTIC SHEET ) |
Demand History | NSN 9330-01-027-6143
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 9330-01-027-6143 | 2015-07-187 | 1 | US |
| 9330-01-027-6143 | 2014-03-70 | 2 | US |
| 9330-01-027-6143 | 2012-11-311 | 2 | United States |
| 9330-01-027-6143 | 2010-09-251 | 300 | DIBBS |
| 9330-01-027-6143 | 2010-04-120 | 215 | DIBBS |
| 9330-01-027-6143 | 2010-04-96 | 20 | DIBBS |
| 9330-01-027-6143 | 2009-10-293 | 175 | DIBBS |
Cross Reference | NSN 9330-01-027-6143
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 9330-GSC125 | 21916 | INSULGARD CORP |
| LEXAN MR-4000 | 72799 | GENERAL ELECTRIC CO PLASTIC OPN/HDQS SHEET PRODUCT DEPT |
| LEXAN MR10-112 (CLEAR) | 72799 | GENERAL ELECTRIC CO PLASTIC OPN/HDQS SHEET PRODUCT DEPT |
| MARGARD MR-5000 | 72799 | GENERAL ELECTRIC CO PLASTIC OPN/HDQS SHEET PRODUCT DEPT |
| TUFFAK CM2 | 4C2N6 | ARKEMA INC. DBA RESEARCH & DEVELOPMENT CENTER |
| TUFFAK CM2 | 77902 | ROHM AND HAAS COMPANY |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 9330-01-027-6143
Related Products | NSN 9330-01-027-6143
Technical Data | NSN 9330-01-027-6143
| Characteristic | Specifications |
|---|---|
| MATERIAL | PLASTIC |
| NONMETALLIC HARDNESS RATING | NOT RATED |
| MINIMUM TENSILE STRENGTH | 9500 POUNDS PER SQUARE INCH |
| FLEXURAL STRENGTH | 13500 POUNDS PER SQUARE INCH |
| MATERIAL TRANSPARENCY | CLEAR |
| COLOR | CLEAR |
| LENGTH | 96.000 INCHES NOMINAL |
| WIDTH | 48.000 INCHES NOMINAL |
| THICKNESS | 0.125 INCHES NOMINAL |
| MANUFACTURERS CODE | 72799 |
| DESIGN CONTROL REFERENCE | LEXAN MR10-112 (CLEAR) |
Restrictions/Controls & Freight Information | NSN 9330-01-027-6143
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 156830 | PLASTIC/RUBR FILM/SHEETING |
| Less than car load rating | ||
| Less than truck load rating | T | 55.0 |
| Water commodity Code | 772 | unknown |
| Originating Activity Code | CX | Defense Supply Center Richmond Richmond, VA 23297-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 9330-01-027-6143
Army
Navy| Category | Code | Description |
|---|---|---|
| Materiel Category and Inventory Manager | J | Ground Forces Support Materiel (DLA/GSA Items) |
| Appropriation and Budget Activity | 2 | Stock Fund Secondary Items |
| Management Inventory Segment | 2 | NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable. |
| Specific Group/Generic Code | 0 | Medical Materiel |
| Weapons Systems/End Item or Homogeneous Group | 00 | DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item |
| Accounting Requirements Code | X | Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DA | Department of the Army |
| Service Organization | A | U.S. Army |
| Reparability | Z | This is a nonreparable item. If condemned or economically unserviceable, then dispose at the level authorized replace the item. |
| Acquisition Advice Codes | Y | TERMINAL ITEM #(NON-STOCKED ITEMS) Future procurement is not authorized. No wholesale stock is available for issue. 1. Requisitions will not be processed to the wholesale manager. 2. Internal Service/agency requisitioning may be continued in accordance with the Service/agency requisitioning policies. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 SH : Sheet |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Y | TERMINAL ITEM #(NON-STOCKED ITEMS) Future procurement is not authorized. No wholesale stock is available for issue. 1. Requisitions will not be processed to the wholesale manager. 2. Internal Service/agency requisitioning may be continued in accordance with the Service/agency requisitioning policies. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 SH : Sheet |
