NSN 8140-01-117-0806 WS21616, 01-117-0806, 011170806
Product Details | AMMUNITION SHIPPING AND STORAGE CRATE
8140-01-117-0806 A reusable item of frame construction or consisting, in all parts, of equally spaced boards. The item is designed to accommodate ammunition during storage, handling, and/or shipment. Excludes: BOX, AMMUNITION.
Part Alternates: WS21616, 8140-01-117-0806, 01-117-0806, 8140011170806, 011170806
Containers, Packaging, and Packing Supplies | Ammunition and Nuclear Ordnance Boxes, Packages and Special Containers
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 81 | 08 AUG 1981 | 01-117-0806 | 33227 ( CRATE, SHIPPING AND STORAGE, AMMUNITION ) |
Cross Reference | NSN 8140-01-117-0806
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| WS21616 | 10001 | NAVAIR AND NAVSEA MANAGED ORIGINAL DESIGN ACTIVITY DWG NOT |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 8140-01-117-0806
Related Products | NSN 8140-01-117-0806
Technical Data | NSN 8140-01-117-0806
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL |
| ASSEMBLY FORM | SET-UP |
| HANDLING FACILITY TYPE | PALLET |
| ASSEMBLY METHOD | WELDED |
| CLOSURE METHOD | DETACHABLE COVER |
| REINFORCEMENT METHOD | ANGLE IRON |
| MAXIMUM WEIGHT CAPACITY | 1000.00 POUNDS |
| STACKING FEATURE | NO |
| USAGE DESIGN | DOMESTIC |
| SPECIAL FEATURES | USED FOR STORING HIGHLY PILFERAB-LE AMMUNITION ITEMS;CRATE MODEL NO.MK 108 MOD 0;PALLET MODEL MK 3 MOD 0;THE BASE OF THE PALLET CRATE SHALL PERMIT ENTRY AND USE OF SLING PALLET HOISTING,MK 70 MOD 2 |
| MANUFACTURERS CODE | 10001 |
| DESIGN CONTROL REFERENCE | WS21616 |
Restrictions/Controls & Freight Information | NSN 8140-01-117-0806
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 029790 | BOXES R CHESTS TOOL/FISH TACKLE |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 691 | unknown |
| Originating Activity Code | JG | Naval Ordnance Center Mechanicsburg, PA 17055-0788 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 8140-01-117-0806
Army| Category | Code | Description |
|---|---|---|
| Materiel Category and Inventory Manager | E | General Supplies (DLA/GSA Items) |
| Appropriation and Budget Activity | 2 | Stock Fund Secondary Items |
| Management Inventory Segment | 2 | NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable. |
| Specific Group/Generic Code | 0 | Medical Materiel |
| Weapons Systems/End Item or Homogeneous Group | 00 | DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item |
| Accounting Requirements Code | X | Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DA | Department of the Army |
| Service Organization | A | U.S. Army |
| Reparability | Z | This is a nonreparable item. If condemned or economically unserviceable, then dispose at the level authorized replace the item. |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
