NSN 6685-01-572-0082 30-04.0-A-1-10-S-4, 30040A110S4, 01-572-0082
Product Details | BIME SELF-INDICATING THERMOMETER
6685-01-572-0082 A thermometer which has a bimetallic substance, whose measurable physical properties, or one of them, change with variation in temperature and self-indicate the temperature to a division or number on a graduated scale(s).
Part Alternates: 30-04.0-A-1-10-S-4, 30040A110S4, 6685-01-572-0082, 01-572-0082, 6685015720082, 015720082
Instruments and Laboratory Equipment | Pressure, Temperature, and Humidity Measuring and Controlling Instruments
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 66 | 24 FEB 2009 | 01-572-0082 | 07329 ( THERMOMETER, SELF-INDICATING, BIMETALLIC ) |
Demand History | NSN 6685-01-572-0082
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 52923894 | 2020-08-218 | 1 | DIBBS |
| 30040D110S4ZZ | 2020-07-204 | 1 | DIBBS |
Cross Reference | NSN 6685-01-572-0082
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 30-04.0-A-1-10-S-4 | 60586 | TREND INSTRUMENTS INC |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 6685-01-572-0082
Related Products | NSN 6685-01-572-0082
Technical Data | NSN 6685-01-572-0082
| Characteristic | Specifications |
|---|---|
| SCALE TYPE | DIAL |
| STYLE DESIGNATOR | ADJUSTABLE ANGLE |
| DESIGN TYPE | FLUCTUATING |
| END ITEM IDENTIFICATION | MISC PARTS INTRR COMMUNICATION LCS 0001 |
| MATERIAL | STEEL COMP 304 PIERCING POINT |
| STEM LENGTH | 4.000 INCHES NOMINAL |
| SPECIAL FEATURES | STANDARD WITH RTD THERMOCOUPLE BLOCK; CONNECTION: 1/2 INCH NPT; 3.000 IN. BACK WITH RESET; CRYSTAL MATL: SHATTERPROOF; WINDOW: FULLY GASKETED GLASS; HERMETIC SEAL PER ASME B40.3 |
| SCALE MEASUREMENT RANGE | +0.000/+250.000 DEG CELSIUS |
| MATERIAL | ALUMINUM ALLOY DIAL FACE |
| MATERIAL | STEEL COMP 304 METER CASE |
| OVERALL LENGTH | 5.500 INCHES NOMINAL |
| DIAL DIAMETER | 3.000 INCHES NOMINAL |
Restrictions/Controls & Freight Information | NSN 6685-01-572-0082
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 058360 | THERMOMETERS,O/THAN CLINICAL |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 652 | unknown |
| Originating Activity Code | HD | Naval Inventory Control Point Mechanicsburg, PA 17055-0788 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Q | Extremely fragile items including delicate instruments. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 6685-01-572-0082
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
