NSN 6680-00-203-2388 693012, 00-203-2388, 002032388
Product Details | TACHOMETER GENERATOR
6680-00-203-2388 A generator consisting of a series of mounted coils surrounding a rotating permanent magnet or a permanent magnet and a rotating armature. The voltage output is directly proportional to the speed of rotation of the shaft. When used with an associated indicator, transmits such data as revolutions per minute, speed of travel, and the like. May also be used in servomechanism loops as a system stabilizer. Excludes rotary inverters, rotary converters, motor generators, dynamotors, generator sets, synchros, frequency or phase changers, and engine accessory generators.
Part Alternates: 693012, 6680-00-203-2388, 00-203-2388, 6680002032388, 002032388
Instruments and Laboratory Equipment | Liquid and Gas Flow, Liquid Level, and Mechanical Motion Measuring Instruments
Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
---|---|---|---|
66 | 01 JAN 1961 | 00-203-2388 | 20241 ( GENERATOR, TACHOMETER ) |
Cross Reference | NSN 6680-00-203-2388
Part Number | Cage Code | Manufacturer |
---|---|---|
693012 | 99193 | HONEYWELL INTERNATIONAL INC. DBA HONEYWELL |
Request a Quote
What Our Customers Say
Compare
Related Products | NSN 6680-00-203-2388
Technical Data | NSN 6680-00-203-2388
Characteristic | Specifications |
---|---|
OVERALL LENGTH | 2.687 INCHES |
OVERALL WIDTH | 2.204 INCHES |
OVERALL HEIGHT | 3.376 INCHES |
LENGTH OF SHAFT FROM HOUSING | 0.655 INCHES SINGLE END |
TERMINAL TYPE AND QUANTITY | 1 CONNECTOR, PLUG |
SHAFT END CHARACTERISTIC | A15 SINGLE STYLE SINGLE END |
SHAFT DIAMETER | 0.310 INCHES MINIMUM AND 0.312 INCHES MAXIMUM SINGLE END |
WIDTH ACROSS FLATS | 0.243 INCHES MINIMUM AND 0.245 INCHES MAXIMUM SINGLE END |
FEATURES PROVIDED | HORIZONTAL MOUNTING POSITION AND VERTICAL MOUNTING POSITION |
MANUFACTURERS CODE | 99193 |
DESIGN CONTROL REFERENCE | 693012 |
Restrictions/Controls & Freight Information | NSN 6680-00-203-2388
Category | Code | Description |
---|---|---|
Shelf-Life Code: | 0 | Nondeteriorative |
Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
Controlled Inventory Item Code: | U | UNCLASSIFIED |
Precious Metals Indicator Code: | U | Precious metal type is unknown |
Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
Category | Code | Description |
---|---|---|
NMF Description | 062120 | GENERATORS/MOTORS/PARTS NOI |
Less than car load rating | ||
Less than truck load rating | W | Rating Variable |
Water commodity Code | 593 | unknown |
Originating Activity Code | XX | |
Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
Air Special Handling | Z | No special handling required. |
Special Handling Code | 9 | unknonwn |
HAZMAT | ||
Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 6680-00-203-2388
Category | Code | Description |
---|---|---|
Cognizance Codes | 9G | Navy-owned stocks of defense general material Naval Inventory Control Point, Mechanicsburg |
Source of Supply | S9G | Defense Supply Center Richmond Richmond, VA 23297 |
Agency | DN | Department of the Navy |
Service Organization | N | U.S. Navy |
Acquisition Advice Codes | Y | TERMINAL ITEM #(NON-STOCKED ITEMS) Future procurement is not authorized. No wholesale stock is available for issue. 1. Requisitions will not be processed to the wholesale manager. 2. Internal Service/agency requisitioning may be continued in accordance with the Service/agency requisitioning policies. |
Controlled Item Code | U | UNCLASSIFIED |
Shelf Life Code | 0 | Nondeteriorative |
Purchasing | QTY UOM |
1 EA : Each |
