Product Details | LABORATORY OVEN

6640-00-022-8349 An oven used in laboratory procedures to remove moisture from materials which are being tested.

Part Alternates: 1324520, 13-245-20, 52349, 6640-00-022-8349, 00-022-8349, 6640000228349, 000228349

Instruments and Laboratory Equipment | Laboratory Equipment and Supplies

Supply Group (FSG) NSN Assign. NIIN
66 28 OCT 1972 00-022-8349

Cross Reference | NSN 6640-00-022-8349

Part Number Cage Code Manufacturer
13-245-20 19631 FISHER SCIENTIFIC CO
52349 08455 UNIVAR CORP VAN WATERS AND ROGERS INC

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 6640-00-022-8349

Technical Data | NSN 6640-00-022-8349

Characteristic Specifications
OPERATING TEMP RANGE IN DEG CELSIUS 35.0 TO 200.0
HEAT SOURCE FOR WHICH DESIGNED INTEGRAL
HEATING METHOD ELECTRICAL
CURRENT TYPE AC
VOLTAGE RATING 115.000 VOLTS NOMINAL
FREQUENCY RATING 60.0 HERTZ NOMINAL
PHASE SINGLE
POWER RATING 1.0 KILOWATTS NOMINAL
CIRCULATION METHOD GRAVITY
WATER JACKET NOT PROVIDED
OUTSIDE HEIGHT 27.625 INCHES NOMINAL
OUTSIDE WIDTH 24.750 INCHES NOMINAL
OUTSIDE DEPTH 19.625 INCHES NOMINAL
INSIDE HEIGHT 18.000 INCHES NOMINAL
INSIDE WIDTH 17.875 INCHES NOMINAL
INSIDE DEPTH 15.250 INCHES NOMINAL
INSULATED CABINET PROVIDED
CABINET OUTER WALL MATERIAL ANY ACCEPTABLE
CABINET INNER WALL MATERIAL ALUMINUM
OUTER DOOR QUANTITY 1
OUTER DOOR INSULATION FEATURE INCLUDED
SHELF QUANTITY ANY ACCEPTABLE
SHELF ADJUSTABILITY ADJUSTABLE
SHELF MATERIAL ANY ACCEPTABLE
VACUUM CHAMBER NOT INCLUDED
CONTROL TYPE THERMOSTAT

Restrictions/Controls & Freight Information | NSN 6640-00-022-8349

Category Code Description
Hazardous Material Indicator CodePThere is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product
Demilitarization Code:ANon-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Electro-static Discharge Susceptible:ANo known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity
Precious Metals Indicator Code:AItem does not contain precious metal
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Automatic Data Processing Equipment:0Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9)
Category Code Description
No Freight Information
