NSN 6625-01-297-5305 PSD 60-1AF, PSD601AF, 01060500
Product Details | CAPACITANCE-RESISTANCE BRIDGE
6625-01-297-5305 A test set specifically designed for use in making examinations and providing discrete evaluations of the over-all performance of a system(s) or subsystem(s). Excludes TEST SET (1), ANTENNA SYSTEM; TEST SET (1), FIRE CONTROL SYSTEM; TEST SET (1), FLIGHT CONTROL SYSTEM; and TEST SET (1), TELEMETERING SYSTEM.20249200058Aircraft Maintenance and Repair Shop Specialized Equipment66250070Electrical and Electronic Properties Measuring and Testing Instruments
Part Alternates: PSD 60-1AF, PSD601AF, 01060500, 01-0605-00, 6625-01-297-5305, 01-297-5305, 6625012975305, 012975305
