NSN 4920-01-419-3264 AN/PLM-3, ANPLM3, 2643382

Product Details | ELECTRONIC SYSTEMS TEST SET

4920-01-419-3264 A test set specifically designed for use in making examinations and providing discrete evaluations of the over-all performance of a system(s) or subsystem(s). Excludes TEST SET (1), ANTENNA SYSTEM; TEST SET (1), FIRE CONTROL SYSTEM; TEST SET (1), FLIGHT CONTROL SYSTEM; and TEST SET (1), TELEMETERING SYSTEM.20249200058Aircraft Maintenance and Repair Shop Specialized Equipment66250070Electrical and Electronic Properties Measuring and Testing Instruments

Part Alternates: AN/PLM-3, ANPLM3, 2643382, 4920-01-419-3264, 01-419-3264, 4920014193264, 014193264

Maintenance and Repair Shop Equipment | Aircraft Maintenance and Repair Shop Specialized Equipment

Supply Group (FSG)	NSN Assign.	NIIN	Item Name Code (INC)
49	19 SEP 1995	01-419-3264	61201 ( TEST SET, ELECTRONIC SYSTEMS )

Drawings & Photos | NSN 4920-01-419-3264

Part Number	Request Date	QTY	Origin
ANPLM3	2019-09-248	1	US
4920-01-419-3264	2019-08-241	1	US
4920-01-419-3264	2015-04-112	2	US
2643382	2013-11-323	4	United States
4920-01-419-3264	2013-11-323	4	MANUAL
4920-01-419-3264	2007-09-247	1	United States
4920-01-419-3264	2007-06-159	1	United States
2643382	2007-05-150	1	US

Cross Reference | NSN 4920-01-419-3264

Part Number	Cage Code	Manufacturer
2643382	06424	ALLIANT TECHSYSTEMS OPERATIONS LLC DIV DEFENSE ELECTRONIC SYSTEMS
AN/PLM-3	80058	JOINT ELECTRONICS TYPE DESIGNATION SYSTEM

Request a Quote

What Our Customers Say

Thank you very much for the excellent service and professional customer care.

Ernie G. Honeywell

The service was excellent. I can think of no improvements to date that you can make regarding internet sales.

John L. Raytheon

The representative for WBParts was efficient & handled our request in a timely & professional manner.

Karen G. General Dynamics

Tried two other sources, neither of them responded, was all done online, never spoke to anyone.

Rex S. US Airforce

The response is quick and the price is often very good. We are completely satisfied.

Patricia S. NASA

Compare

NSNs for Compare ( up to 4 ): Add 4920-01-419-3264

Compare

Related Products | NSN 4920-01-419-3264

4920-01-419-3528, 4920-01-419-4122, 4920-01-419-4239, 4920-01-419-4367, 4920-01-419-4368

Technical Data | NSN 4920-01-419-3264

Characteristic	Specifications
TEST TYPE FOR WHICH DESIGNED	MEASURE PERFORMANCE HISTORY OF THE OSC TO VERIFY THAT THERE IS NO DEGRADATION IN THE OSC
INCLOSURE FEATURE	SINGLE ITEM W/CARRYING CASE
SPECIAL FEATURES	STIMULATOR TEST SET C-17 AN/AAR-47 AND AN/ALE-47
III END ITEM IDENTIFICATION	C-17
III SUPPLEMENTARY FEATURES	TO NAME: TEST SET, SENSOR STIMULATOR
III FUNCTIONAL DESCRIPTION	USED AT THE ORGANIZATIONAL LEVEL TO MEASURE THE PERFORMANCE HISTORY OF THE OSC TO VERIFY THAT THERE IS NO DEGRADATION IN THE OSC.MUST BE CAPABLE OFPROVIDING A CALIBRATED LEVEL OF IRRADIANCE
III REFERENCE DATA AND LITERATURE	TO 1C-17A-4-4; SERD 760504
MANUFACTURERS CODE	06424
DESIGN CONTROL REFERENCE	2643382
