NSN 6625-00-781-0854 102, 00-781-0854, 007810854
Product Details | MULTIMETER
6625-00-781-0854 An instrument which is arranged to measure two or more different electrical quantities (such as volts, amps, and ohms) by means of associated circuits and switches. The value is usually expressed on a single calibrated dial or digital readout display. For items which are connected into a circuit and used chiefly to visually monitor an operation, see METER, MULTIPLE SCALE. See also COUNTER, ELECTRONIC, DIGITAL READOUT. Excludes BRIDGE (as modified).
Part Alternates: 102, 6625-00-781-0854, 00-781-0854, 6625007810854, 007810854
Instruments and Laboratory Equipment | Electrical and Electronic Properties Measuring and Testing Instruments
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 66 | 01 JAN 1960 | 00-781-0854 | 00794 ( MULTIMETER ) |
Drawings & Photos | NSN 6625-00-781-0854
Demand History | NSN 6625-00-781-0854
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 102 | 2011-08-229 | 94 |
Cross Reference | NSN 6625-00-781-0854
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 102 | 08596 | ELECTRONIC MEASUREMENTS CORP |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 6625-00-781-0854
Technical Data | NSN 6625-00-781-0854
| Characteristic | Specifications |
|---|---|
| (NON-CORE DATA) CIRCUIT CONSTRUCTION TYPE | NONELECTRONIC |
| MEASUREMENT RANGE | 0.0 TO 1.3 AMPERES, DC SINGLE INDICATOR 1ST RANGE 0.0 TO 1.0 MEGOHMS SINGLE INDICATOR 2ND RANGE 0.0 TO 600.0 MILLIAMPERES, AC SINGLE INDICATOR 3RD RANGE 0.0 TO 3.0 VOLTS, AC SINGLE INDICATOR 4TH RANGE 0.0 TO 3.0 VOLTS, AC SINGLE INDICATOR 5TH RANGE 0.0 TO 3.0 VOLTS, DC SINGLE INDICATOR 6TH RANGE |
| ACCURACY IN PERCENT | -2.0 TO 2.0 AT FULL SCALE SINGLE INDICATOR ALL RANGES |
| SCALE GRADUATION TYPE | NONLINEAR SINGLE INDICATOR SINGLE RANGE |
| SCALE DIVISION QUANTITY | 6 SINGLE INDICATOR SINGLE RANGE |
| SENSITIVITY RATING | 1.0 MILLIAMPERES |
| POWER SOURCE | INTERNAL |
| STYLE DESIGNATOR | D1 RECTANGULAR OR SQUARE |
| OVERALL HEIGHT | 6.375 INCHES NOMINAL |
| OVERALL LENGTH | 2.250 INCHES NOMINAL |
| OVERALL WIDTH | 3.750 INCHES NOMINAL |
| MATERIAL | PLASTIC |
| FURNISHED ITEMS AND QUANTITY | TWO TEST CABLES |
| FEATURES PROVIDED | PORTABLE |
Restrictions/Controls & Freight Information | NSN 6625-00-781-0854
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
