NSN 6625-00-781-1529 15A219555, 8644053501, 8644053-501
Product Details | INDICATOR HOUSING
6625-00-781-1529 00020811900057Specialized Test and Handling Equipment, Nuclear Ordnance66050024Navigational Instruments66100018Flight Instruments66200018Engine Instruments66250070Electrical and Electronic Properties Measuring and Testing Instruments66800078Liquid and Gas Flow, Liquid Level, and Mechanical Motion Measuring Instruments66850073Pressure, Temperature, and Humidity Measuring and Controlling Instruments66950041Combination and Miscellaneous Instruments
Part Alternates: 15A219555, 8644053501, 8644053-501, 6625-00-781-1529, 00-781-1529, 6625007811529, 007811529
Instruments and Laboratory Equipment | Electrical and Electronic Properties Measuring and Testing Instruments
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 66 | 01 JAN 1960 | 00-781-1529 | 22406 ( HOUSING, INDICATOR ) |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 6625-00-781-1529
Technical Data | NSN 6625-00-781-1529
| Characteristic | Specifications |
|---|---|
| MATERIAL | ALUMINUM |
| SURFACE TREATMENT | ENAMEL |
| DIAL WINDOW | NOT INCLUDED |
| DIAL FRAME | NOT INCLUDED |
| MOUNTING CONFIGURATION | FOUR 0.220 IN; DIA MTG HOLES IRREGULARLY SPACED |
| OVERALL WIDTH | 3.174 INCHES NOMINAL |
| OVERALL HEIGHT | 3.174 INCHES NOMINAL |
| OVERALL DEPTH | 4.440 INCHES NOMINAL |
| III FSC APPLICATION DATA | RADAR SET AIRBORNE,EXCEPT FIRE CONTROL AND GUIDED MISSILE |
| MANUFACTURERS CODE | 49671 |
| DESIGN CONTROL REFERENCE | 8644053-501 |
Restrictions/Controls & Freight Information | NSN 6625-00-781-1529
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 133300 | MACHINERY/MACHINES NOI |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 652 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 6625-00-781-1529
Air Force| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Materiel Management Aggregation Code | CW | TG:AIRBORNE RADAR AND MISCELLANEOUS ELECTRONIC EQUIPMENT |
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Price Validation | V | The current standard price has been validated.
|
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
