Product Details | OSCILLOSCOPE SUBASSEMBLY

6625-00-049-8601 Two or more different types of items, having a common mounting or mounted on each other, which together form a portion of an oscilloscope, but which in itself is not a complete functioning item and cannot be assigned a more definite item name.

Part Alternates: DEC040A01, DEC040GPA01, DEC040GPA01REV2, DEC040REV1GPA01, 6625-00-049-8601, 00-049-8601, 6625000498601, 000498601

Instruments and Laboratory Equipment | Electrical and Electronic Properties Measuring and Testing Instruments

Supply Group (FSG) NSN Assign. NIIN
66 01 JAN 1963 00-049-8601

Cross Reference | NSN 6625-00-049-8601

Part Number Cage Code Manufacturer
DEC040A01 0ZW31 MEASUREMENT SPECIALTIES, INC. DBA IC SENSORS DIVISION
DEC040GPA01 0ZW31 MEASUREMENT SPECIALTIES, INC. DBA IC SENSORS DIVISION
DEC040GPA01REV2 0ZW31 MEASUREMENT SPECIALTIES, INC. DBA IC SENSORS DIVISION
DEC040REV1GPA01 0ZW31 MEASUREMENT SPECIALTIES, INC. DBA IC SENSORS DIVISION

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 6625-00-049-8601

Technical Data | NSN 6625-00-049-8601

Characteristic Specifications
COMPONENT TYPE AND QUANTITY 2 CAPACITOR AND 10 RESISTOR AND 1 SWITCH
END ITEM IDENTIFICATION TYPE AN/USM-24C
OVERALL LENGTH 3.094 INCHES NOMINAL
OVERALL HEIGHT 1.875 INCHES NOMINAL
OVERALL WIDTH 1.625 INCHES NOMINAL
SPECIAL FEATURES USAGE DESIGN:TRIGGER GENERATOR SWITCH ASSY;MOUNTING CONFIGURATION:0.375 IN.-32 THREADED BUSHING 0.375 IN.LG
MANUFACTURERS CODE 0ZW31
DESIGN CONTROL REFERENCE DEC040REV1GPA01
