NSN 6625-00-542-1444 MS29561234, MS29561-234 , SMB338089
Product Details | OSCILLOSCOPE SUBASSEMBLY
6625-00-542-1444 Two or more different types of items, having a common mounting or mounted on each other, which together form a portion of an oscilloscope, but which in itself is not a complete functioning item and cannot be assigned a more definite item name.
Part Alternates: MS29561234, MS29561-234 , SMB338089, 200Z501, 2-234 47-071 , 2-234 N4771-70 , 2234N477170, 2341467, 234-1467 , 6625-00-542-1444, 00-542-1444, 6625005421444, 223447071, 005421444
Instruments and Laboratory Equipment | Electrical and Electronic Properties Measuring and Testing Instruments
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 66 | 01 JAN 1961 | 00-542-1444 | 00606 ( OSCILLOSCOPE SUBASSEMBLY ) |
Drawings & Photos | NSN 6625-00-542-1444
Demand History | NSN 6625-00-542-1444
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| MS29561234 | 2006-07-189 | 10 | Austria |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 6625-00-542-1444
Related Products | NSN 6625-00-542-1444
Technical Data | NSN 6625-00-542-1444
| Characteristic | Specifications |
|---|---|
| COMPONENT TYPE AND QUANTITY | 7 CAPACITOR AND 3 REACTOR |
| END ITEM IDENTIFICATION | TYPE NO. AN/USM-50 |
| OVERALL LENGTH | 4.563 INCHES NOMINAL |
| OVERALL DIAMETER | 2.875 INCHES NOMINAL |
| SPECIAL FEATURES | A.STAMPED GND,1,2,3,4,5,6,7,8,9,10;COMPONEN T TYPE AND QUANTITY:TAPPED INDUCTANCES 2;USAGE DESIGN:CONTAINS THE FIVE RESONANT CIRCUITS FOR OSCILLATOR IN THE MARKER GENERATOR;MOUNTING CONFIGURATION:MOUNTS BY THREE NO. 8-32 THD STUDS;FSC APPLICATION DATA:OSCILLOSCOPE SUBASSEMBLIES,EXCEPT SPECIALLY DESIGNED |
Restrictions/Controls & Freight Information | NSN 6625-00-542-1444
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 194120 | WASHERS/GASKETS/PCKG DVCS NOI |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 596 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
